Ford Transit Base (2004) price & specs
Save $$$ with CarExpert*
From
$36,340â€
Base
Overview
The 2004 Ford Transit Base is a rear-wheel drive, 4-door Panel Van that was released to the Australian market on 4th January 1970 classified as a VJ. The Ford Transit is regarded as a Van Over 3.5t built in Great Britain with prices starting at $36,340 before on-road costs.
This Ford Transit is powered by a 2.4L 4-cylinder engine that has 85 kW of power (at 3800 rpm) and 285 Nm of torque (at 2300 rpm) via a Five-speed Manual transmission. It has a 80L fuel tank
The Ford Transit measures 2363mm (93.0 inches) in height, 5651mm (222.5 inches) in length, 1974mm (77.7 inches) in width with a 3750mm (147.6 inches) wheelbase that brings about a total of 1798kg (3963.9 lbs) of unladen weight. The Transit Base comes standard with 215/75 R16 front tyres and 215/75 R16 rear tyres. It has a 36 month, 100,000 km warranty.
Trusted Reviews, Smarter Choices, Better Prices
Where expert car reviews meet expert car buying – CarExpert gives you trusted advice, personalised service and real savings on your next new car.
How does the Transit compare?
Quickly see how the 2004 Ford Transit Base stacks up against its competition.
 Select any benchmark to see more details.
Power to Weight
42.59 - 65.56 kW/t
42.59 kW/t
65.56 kW/t
Price
$32,700 - $47,780
$32,700
$47,780
Warranty (Years)
3 years
3 years
Warranty (Distance)
100,000 km
100,000 km
Years on Sale
6 - 7 years
1 year
5 years
Trusted Reviews, Smarter Choices, Better Prices
Where expert car reviews meet expert car buying – CarExpert gives you trusted advice, personalised service and real savings on your next new car.
Dimensions
5,651 mm
1,974 mm
2,363 mm
| Specification | Measurement |
|---|---|
| Overall Length | 5,651 mm |
| Overall Width | 1,974 mm |
| Overall Height | 2,363 mm |
| Wheelbase | 3,750 mm |
| Turning Circle | 13,300 mm |
| Load Capacity | 1,752 mm |
Looking for complete Ford Transit size & space specs?
Our Ford Transit Exterior and Dimensions Page has every measurement you need to know exactly how this vehicle will fit your driving, garage, or work needs.
Explore Ford Transit Features & Specs
Compressor
Compressor: Turbo
Engine
Bore Engine: 89.9
Engine (cc): 2402
Compression Ratio: 19
Engine Configuration: In-Line
Engine (L): 2.4
Number of Cylinders: 4
Number of Valves per Cylinder: 4
Stroke Engine: 94.6
Valve Gear Type: Overhead Cam
Fuel
Generic Primary Fuel Type: Diesel
Fuel Type: Diesel
Fuel System
Injection Carburetion: Diesel Direct Injection
Fuel Tanks
Main Capacity Gal: 21.1
Main Capacity (L): 80
Main Fuel Type: Diesel
Main Type: Total
Power
Maximum Power (hp/PS): 116
Maximum Power (kW): 85
Maximum Torque (Nm): 285
Measurement Standard: EEC
Rpm For Maximum Power Low: 3800
Rpm For Maximum Torque Low: 2300
Drive
Driven Wheels: Rear
Electronic Traction Control
Controlled By: Abs & Engine Management
Transmission
Number of Speeds: 5
Type: Manual
ABS
Location: 4-Wheel
Disc Brakes
Number of Disc Brakes: 2
Number of Ventilated Disc Brakes: 2
Suspension
Location: Front
Front Spring Type: Coil
Front Stabilizer Bar: yes
Front Type: Strut
Front Wheel Dependence: Independent
Location: Rear
Rear Spring Type: Leaf
Rear Type: Beam
Rear Wheel Dependence: Rigid
Tires
Location: Front
Front Wheels Tire Profile: 75
Front Wheels Tire Width: 215
Rear Wheels Tire Location: Rear
Rear Wheels Tire Profile: 75
Rear Wheels Tire Width: 215
Wheels
Location: Front
Front Wheels Rim Diameter (In): 16
Front Wheels Rim Type: Steel
Front Wheels Rim Width (In): 6.5
Location: Rear
Rear Rim Diameter (In): 16
Rear Rim Type: Steel
Rear Wheels Rim Width (In): 6.5
Body Style
Body Type: Panel Van
Cab Type: Single Cab
Driver Location: RHD
Local Body Type: Panel Van
Roof Type: Semi-High
Wheelbase Type: Long
Mud Flaps
Front Mud Flaps Location: Front
Rear Mud Flaps Location: Rear
Step
Step Location: Rear
Bumpers
Front Bumper Colour: Black
Location: Front
Front Bumper Material: Plastic
Rear Bumper Colour: Black
Location: Rear
Rear Bumper Material: Plastic
Cargo Area Dimensions
Cargo Volume (cu ft): 347.9
Cargo Volume (L): 9850
Height (in): 64.8
Height (mm): 1762
Length (in): 133.8
Length (mm): 3399
Loading Floor Height (in): 26.3
Loading Floor Height (mm): 668
Standard Measurement: SAE
Width Between Wheelhouses (in): 54.7
Width Between Wheelhouses (mm): 1390
Width (in): 69.4
Width (mm): 1762
External Dimensions
Kerb to Kerb Turning Circle (mm): 13300
Front Overhang (in): 35.6
Front Overhang (mm): 904
Front Track (in): 66.9
Front Track (mm): 1700
Kerb To Kerb Turning Circle (ft): 43.6
Overall Height (in): 93
Overall Height (mm): 2363
Overall Length (in): 222.5
Overall Length (mm): 5651
Overall Width (in): 77.7
Overall Width (mm): 1974
Rear Overhang (in): 39.3
Rear Overhang (mm): 997
Rear Track (in): 66.9
Rear Track (mm): 1700
Wheelbase (in): 147.6
Wheelbase (mm): 3750
Cargo Doors
Driver Height (in): 57.7
Driver Height (mm): 1465
Driver Internal Handles: yes
Driver Location: Driver
Driver Opening Angle: 0
Driver Operation: Sliding
Driver Width (in): 50.2
Driver Width (mm): 1275
Passenger Height (in): 57.7
Passenger Height (mm): 1465
Passenger Internal Handles: yes
Location: Passenger
Passenger Opening Angle: 0
Passenger Operation: Sliding
Passenger Width (in): 50.2
Passenger Width (mm): 1275
Rear Height (in): 61.7
Rear Height (mm): 1566
Rear Internal Handles: yes
Location: Rear
Rear Opening Angle: 180
Rear Operation: Double Hinged
Rear Width (in): 60.6
Rear Width (mm): 1540
Doors
Location: Driver
Driver Door Type: Front Hinged
Location: Passenger
Passenger Door Type: Front Hinged
Location: Rear Passenger
Rear Passenger Door Type: Sliding
Headlight Control
Internal Height Adjustment: yes
Headlights
Low Beam Bulb Type: Halogen
Lens Type: Complex Surface
Paint
Type: Gloss
Door Mirrors/Cameras
Driver Door Mirrors/Cameras Colour: Black
Mirrors/Cameras Location: Driver
Driver Door Mirrors/Cameras Type: Externally Adjustable
Wide Angle Driver Door Mirrors/Cameras: yes
Passenger Door Mirrors/Cameras Colour: Black
Mirrors/Cameras Location: Passenger
Passenger Door Mirrors/Cameras Type: Externally Adjustable
Wide Angle Passenger Door Mirrors/Cameras: yes
Power Windows
Front Electric Windows: Front
Windshield Wipers
Intermittent Wipe Windshield Wipers: Fixed
Weights
Front Axle Weight (kg): 1463
Front Axle Weight (lb): 3225
Gross Trailer Weight Braked (kg): 2750
Gross Trailer Weight Braked (lb): 6063
Gross Trailer Weight Unbraked (kg): 750
Gross Trailer Weight Unbraked (lb): 1653
Gross Vehicle Weight (kg): 3550
Gross Vehicle Weight (lb): 7826
Payload Allowance (kg): 1672
Payload Allowance (lb): 3686
Published Kerb Weight (kg): 1798
Published Kerb Weight (lb): 3964
Rear Axle Weight (kg): 2037
Rear Axle Weight (lb): 4491
Audio Anti-Theft Protection
Type: Detachable Panel
Type: Code
Audio System
Cassette Player: yes
Radio Type: Am/Fm
System Type: Stereo
Speakers
Number of Speakers: 2
Load Restraint
Type: Hooks
Cigar Lighter
Location: Front Seats
Floor Covering
Vehicle Cab Compartment: Plastic/Rubber
Load Area Side Covering
Exposed Metal: Partial
Type: Board
Front Airbag
Location: Driver
Location: Passenger
Front Seat Belts
Center Operation: Reel
Center Seat Position: Center
Center Type: 3-Point
Driver Height Adjustable: yes
Driver Operation: Reel
Driver Pre Tensioners: yes
Driver Seat Position: Driver
Driver Type: 3-Point
Passenger Operation: Reel
Passenger Seat Position: Passenger
Passenger Type: 3-Point
Head Restraints
Front Seats Height Adjustable: yes
Front Seats Location: Front Seats
Front Seats Number: 3
Front Seat
Location: Centre
Center Front Seat Type: Bench
Driver Front Seat Height Adjustment: yes
Location: Driver
Driver Front Seat Lumbar Adjustment: yes
Driver Front Seat Type: Bucket
Passenger Front Seat Fore/Aft Adjustment: yes
Location: Passenger
Passenger Front Seat Reclining: yes
Passenger Front Seat Type: Bench
Seat Upholstery
Main Seat Material: Cloth
Seating
Capacity: 3
Configuration: 3+0
Cup Holders
Location: Front Seats
Front Seats Type: Pop Out
Door Pockets Bins
Location: Driver
Location: Passenger
Glove Compartment
Lid: yes
Power Locks
Includes Trunk Hatch: yes
Operation: Remote
