    Jeep Wrangler Unlimited Overland (2017) price & specs

    Save $$$ with CarExpert*
    From
    $53,990†
    3.6L petrol5D SUV5 SP AUTOMATIC4x4
    Hero image of a new Jeep Wrangler Unlimited Overland (2017) price & specs available with CarExpert deals.

    Overland

    Find a deal

    Overview

    The 2017 Jeep Wrangler Unlimited Overland is a four-wheel drive, 5-door SUV that was released to the Australian market on 3rd December 2016 classified as a JK. The Jeep Wrangler Unlimited is regarded as a large SUV built in USA with prices starting at $53,990 before on-road costs.

    This Jeep Wrangler Unlimited is powered by a 3.6L 6-cylinder engine that has 209 kW of power (at 6350 rpm) and 347 Nm of torque (at 4300 rpm) via a Five-speed Automatic transmission. Jeep claims the Wrangler Unlimited Overland uses 11.7L/100km of Unleaded in the combined city and highway cycle while putting out 273g of CO2. It has a 85L fuel tank, meaning it should be able to travel 726km per full tank

    The Jeep Wrangler Unlimited measures 1865mm (73.4 inches) in height, 4751mm (187.0 inches) in length, 1877mm (73.9 inches) in width with a 2947mm (116.0 inches) wheelbase that brings about a total of 1919kg (4230.7 lbs) of unladen weight. The Wrangler Unlimited Overland comes standard with 255/70 R18 front tyres and 255/70 R18 rear tyres. It requires a service every 12 months or 15,000 km, whichever comes first. It has a 60 month, 100,000 km warranty.

    The 2017 Jeep Wrangler Unlimited Overland has a 220mm ground clearance with a 2300kg braked and 750kg unbraked towing capacity.

    Trusted Reviews, Smarter Choices, Better Prices

    Where expert car reviews meet expert car buying – CarExpert gives you trusted advice, personalised service and real savings on your next new car.

    Compare CarsFind a deal

    How does the Wrangler Unlimited compare?

    Quickly see how the 2017 Jeep Wrangler Unlimited Overland stacks up against its competition.
     Select any benchmark to see more details.

    Power to Weight
    73.57 - 109.54 kW/t
    56.4 kW/t
    120.05 kW/t
    Boot Space
    498 litres
    131 litres
    742 litres
    Fuel Efficiency
    8.3 - 11.9 L/100km
    5.7 L/100km
    11.9 L/100km
    Vehicle Range
    714 - 1,024 km
    606 km
    1,215 km
    Price
    $42,990 - $53,990
    $35,740
    $76,990
    Warranty (Years)
    5 years
    3 years
    7 years
    Warranty (Distance)
    100,000 km
    100,000 km
    Unlimited
    Years on Sale
    2 years
    1 year
    5 years
    Service Interval
    12 months
    3 months
    12 months

    Towing & Off-Road Capability

    Gross Vehicle Weight
    2,540 - 2,585 kg
    2,100 kg
    3,300 kg
    Braked Towing Capacity
    2,300 kg
    1,500 kg
    3,500 kg
    Approach Angle
    35°
    14.7°
    36.6°
    Departure Angle
    28°
    15.3°
    28°
    Ground Clearance Unladen
    220 mm
    180 mm
    235 mm

    Trusted Reviews, Smarter Choices, Better Prices

    Where expert car reviews meet expert car buying – CarExpert gives you trusted advice, personalised service and real savings on your next new car.

    Compare CarsFind a deal

    Dimensions

    4,751 mm
    1,877 mm
    1,865 mm
    SpecificationMeasurement
    Overall Length4,751 mm
    Overall Width1,877 mm
    Overall Height1,865 mm
    Wheelbase2,947 mm
    Turning Circle12,250 mm
    Load Capacity621 mm

    Looking for complete Jeep Wrangler Unlimited size & space specs?

    Our Jeep Wrangler Unlimited Exterior and Dimensions Page has every measurement you need to know exactly how this vehicle will fit your driving, garage, or work needs.

    Explore Jeep Wrangler Unlimited Features & Specs

    Overland

    3.6L, 5-speed auto, 5-door SUV, Petrol, 4x4

    Save $$$ with CarExpert*
    $53,990†
    Find a deal

    Emission Control Level

    Australia Air Pollution Rating: 8.5
    Australia Greenhouse Rating: 4.5
    Australia Overall Emission Control Level Rating: 3.5
    CO2 Level (Combined): 273
    Standard Met: EU5

    Engine

    Bore Engine: 96.0
    Engine (cc): 3604
    Engine Configuration: V
    Engine Code: ERB
    Engine (L): 3.6
    Number of Cylinders: 6
    Number of Valves per Cylinder: 4
    Stroke Engine: 83.0
    Variable Valve Timing Camshaft: yes

    Fuel

    Generic Primary Fuel Type: Petrol
    Minimum Fuel Octane Number: 91
    Minimum Fuel Type: Unleaded
    Fuel Type: Unleaded
    Octane Number: 91

    Fuel System

    Injection Carburetion: Multi-Point Injection

    Fuel Tanks

    Main Capacity Gal: 22.5
    Main Capacity (L): 85
    Main Capacity Uk Gallons: 18.7
    Main Type: Total

    Interested in buying a Jeep Wrangler Unlimited Overland?

    Save $$$ with CarExpert*
    From
    $53,990†
    Find a deal

    Fuel Consumption

    ADR 81/02 Calculated Vehicle Range (km): 726
    ADR 81/02 Calculated Vehicle Range (miles): 451
    ADR 81/02 Combined (km/L): 8.5
    ADR 81/02 Combined (L/100km): 11.7
    ADR 81/02 Combined (miles per UK gallon): 24
    ADR 81/02 Combined (mpg): 20
    ADR 81/02 Country Highway (km/L): 10.9
    ADR 81/02 Country Highway (L/100km): 9.2
    ADR 81/02 Country Highway (miles per UK gallon): 31
    ADR 81/02 Country Highway (mpg): 26
    ADR 81/02 Standard: Adr 81/02
    ADR 81/02 Urban (km/L): 6.2
    ADR 81/02 Urban (L/100km): 16.1
    ADR 81/02 Urban (miles per UK gallon): 18
    ADR 81/02 Urban (mpg): 15

    Fuel Economy

    ADR 81/02 (L/100km): 11.7

    Performance

    Acceleration 0 To 100 km/h: 8.9
    Maximum Speed (km/h): 180
    Maximum Speed (mph): 112

    Power

    Maximum Power (hp/PS): 284
    Maximum Power (kW): 209
    Maximum Torque (Nm): 347
    Measurement Standard: DIN
    Primary or Secondary Fuel Power Figure: Primary
    Rpm For Maximum Power Low: 6350
    Rpm For Maximum Torque Low: 4300

    Drive

    Descent Control System: yes
    Driven Wheels: 4x4
    Four-Wheel Drive Type: Part-Time
    Selection: Manual

    Transmission

    Code: W5a580
    Description: Automatic With Manual Mode
    Low High Gear Ranges: yes
    Manual Mode: yes
    Number of Speeds: 5
    Shift Lever Location: Floor
    Type: Automatic

    Disc Brakes

    Number of Disc Brakes: 4
    Number of Ventilated Disc Brakes: 2

    Steering Wheel

    Height Adjustment: yes
    Type: Leather Covered

    Suspension

    Location: Front
    Front Spring Type: Coil
    Front Stabilizer Bar: yes
    Front Type: Beam
    Front Wheel Dependence: Rigid
    Location: Rear
    Rear Spring Type: Coil
    Rear Stabilizer Bar: yes
    Rear Type: Beam
    Rear Wheel Dependence: Rigid

    Tires

    Front Wheels Tire Load Index: 113
    Location: Front
    Front Wheels Tire Profile: 70
    Front Wheels Tire Speed Rating: S
    Front Wheels Tire Type: All Terrain
    Front Wheels Tire Width: 255
    Rear Wheels Tire Load Index: 113
    Rear Wheels Tire Location: Rear
    Rear Wheels Tire Profile: 70
    Rear Wheels Tire Speed Rating: S
    Rear Wheels Tire Type: All Terrain
    Rear Wheels Tire Width: 255

    Wheels

    Location: Front
    Front Wheels Rim Diameter (In): 18
    Front Wheels Rim Type: Alloy
    Front Wheels Rim Width (In): 7.5
    Front Wheels Two Tone: yes
    Location: Rear
    Rear Rim Diameter (In): 18
    Rear Rim Type: Alloy
    Rear Wheels Rim Width (In): 7.5
    Rear Two Tone: yes

    Body Style

    Body Type: SUV
    Local Body Type: SUV
    Platform Code: JK
    Wheelbase Type: Long

    Mud Flaps

    Rear Mud Flaps Location: Rear

    Underbody Protection

    Location: Fuel Tank
    Location: Transfer Case

    Cargo Capacity

    Measurement Standard: SAE
    Rear Seat Down (cu ft): 33.0
    Rear Seat Down (L): 935
    Rear Seat Up to Lower Window (cu ft): 17.6
    Rear Seat Up to Lower Window (L): 498

    External Dimensions

    Kerb to Kerb Turning Circle (mm): 12250
    Front Track (in): 61.9
    Front Track (mm): 1572
    Ground Clearance Unladen (in): 8.7
    Ground Clearance Unladen (mm): 220
    Kerb To Kerb Turning Circle (ft): 40.2
    Overall Height (in): 73.4
    Overall Height (mm): 1865
    Overall Length (in): 187.0
    Overall Length (mm): 4751
    Overall Width (in): 73.9
    Overall Width (mm): 1877
    Rear Track (in): 61.9
    Rear Track (mm): 1572
    Wheelbase (in): 116.0
    Wheelbase (mm): 2947

    Internal Dimensions

    Front Headroom (in): 42.3
    Front Headroom (mm): 1075
    Rear Headroom (in): 40.4
    Rear Headroom (mm): 1025
    Front Hip Room (in): 54.8
    Front Hip Room (mm): 1393
    Rear Hip Room (in): 54.7
    Rear Hip Room (mm): 1390
    Front Leg Room (in): 40.9
    Front Leg Room (mm): 1040
    Rear Leg Room (in): 36.3
    Rear Leg Room (mm): 921
    Front Shoulder Room (in): 55.7
    Front Shoulder Room (mm): 1415
    Rear Shoulder Room (in): 57.0
    Rear Shoulder Room (mm): 1448

    Ramp Angles

    Approach Angle: 35.0
    Departure Angle: 28.0

    Bumpers

    Location: Front
    Location: Rear

    Doors

    Location: Driver
    Driver Door Type: Front Hinged
    Location: Passenger
    Passenger Door Type: Front Hinged
    Location: Rear Driver
    Rear Driver Door Type: Front Hinged
    Location: Rear Passenger
    Rear Passenger Door Type: Front Hinged

    Rear Door

    Type: Single Hinged

    Headlight Control

    Dusk Sensor: yes
    Height Adjustment: Manual
    Internal Height Adjustment: yes

    Headlights

    High Beam Bulb Type: Halogen
    Low Beam Bulb Type: Halogen
    Lens Type: Complex Surface

    Paint

    External Colour: Black
    Type: Gloss

    Convertible Rollover Protection

    Rollover Protection Type: Fixed Hoop

    Convertible Roof

    Foldable Hard Top Type: Foldable Hard Top

    Sunroof

    Front Sunroof Location: Front
    Front Sunroof Type: Fabric

    Door Mirrors/Cameras

    Driver Door Mirrors/Cameras Colour: Black
    Heated Driver Door Mirrors/Cameras: yes
    Mirrors/Cameras Location: Driver
    Driver Door Mirrors/Cameras Type: Electrically Adjustable
    Passenger Door Mirrors/Cameras Colour: Black
    Heated Passenger Door Mirrors/Cameras: yes
    Mirrors/Cameras Location: Passenger
    Passenger Door Mirrors/Cameras Type: Electrically Adjustable

    Power Windows

    Front Electric Windows: Front

    Rear View Mirror Camera

    Auto Dimming: yes

    Windshield Wipers

    Intermittent Wipe Windshield Wipers: Variable

    Weights

    Gross Trailer Weight Braked (kg): 2300
    Gross Trailer Weight Braked (lb): 5071
    Gross Trailer Weight Unbraked (kg): 750
    Gross Trailer Weight Unbraked (lb): 1653
    Gross Vehicle Weight (kg): 2540
    Gross Vehicle Weight (lb): 5600
    Published Kerb Weight (kg): 1919
    Published Kerb Weight (lb): 4231
    Tare Weight (kg): 1863

    Audio System

    CD Player Reads MP3: yes
    In-Dash CD: yes
    In-Dash DVD: yes
    Radio Type: Am/Fm

    External Connections

    USB (Front): yes

    Remote Audio Controls

    Type: Steering Wheel Mounted

    Speakers

    Brand: Alpine
    Number of Speakers: 7
    Subwoofer: yes

    Bluetooth

    Includes Phone Connection: yes

    Entertainment Display Screen

    Front DVD: yes
    Location: Front
    Front Screen Size (in): 6.5
    Front Touch Screen: yes

    Navigational Systems

    Controls: Touch Screen
    Information Type: 3d And Voice
    Screen Size (in): 6.5

    Parking Distance System

    Location: Rear
    Rear Type: Camera

    Power Outlet 12V

    Location (12V): Front

    Voice Activating System

    Includes Audio Player: yes
    Includes Navigation System: yes
    Includes Phone: yes

    Display Screen

    Location: ?
    Number of Screens: 1
    Screen Size (in): 6.5
    Touch Screen: yes

    Luxury Trim

    Doors: Alloy Look
    Gear Selector: Chrome
    Instrument Panel: Alloy Look

    Airbags

    Number of Airbags: 4

    Front Airbag

    Location: Driver
    Location: Passenger

    Front Seat Belts

    Driver Height Adjustable: yes
    Driver Pre Tensioners: yes
    Driver Seat Position: Driver
    Passenger Height Adjustable: yes
    Passenger Pre Tensioners: yes
    Passenger Seat Position: Passenger

    Head Restraints

    Front Seats Location: Front Seats
    Rear Seats Location: Rear Seats
    Rear Seats Number: 3

    Rear Seat Belts

    Center Seat Position: Centre
    Center Type: 3-Point
    Driver Seat Position: Driver
    Passenger Seat Position: Passenger

    Side Airbag

    Location: Front

    Front Seat

    Driver Front Seat Heated: yes
    Driver Front Seat Height Type: Manual
    Location: Driver
    Driver Front Seat Reach Type: Manual
    Driver Front Seat Reclining Type: Manual
    Driver Front Seat Type: Bucket
    Passenger Front Seat Heated: yes
    Location: Passenger
    Passenger Front Seat Reach Type: Manual
    Passenger Front Seat Reclining Type: Manual
    Passenger Front Seat Type: Bucket

    Seat Upholstery

    Additional Seat Material: Leather
    Main Seat Material: Leather

    Seating

    Capacity: 5
    Configuration: 2+3

    Cup Holders

    Location: Front Seats
    Location: Rear Seats

    Air Conditioning

    Type: Manual

    Power Locks

    Operation: Remote

    Intermediate Service

    Distance (km): 15000
    Distance (miles): 9321
    Period (Months): 12

    * Average savings based on recent CarExpert customer transactions. Actual savings will vary depending on vehicle make and model, location, stock availability, and other factors.

    † Displayed prices exclude on-road costs such as delivery charges, registration fees, number plates, insurance and applicable road taxes. These prices are subject to change without notice and may not reflect current market pricing or dealer offers.

    JATO logoAutomotive Vehicle Spec Data & 4K images Powered by JATO Dynamics Ltd
    Â
