S10+
2.2L, 6-speed manual, 4-door Cab Chassis, Diesel, 4x4
Save $$$ with CarExpert*
$34,500â€
S10+
Overview
The 2022 Mahindra Pik-Up S10+ is a four-wheel drive, 4-door Cab Chassis that was released to the Australian market on 2nd November 2022. The Mahindra Pik-Up is regarded as a Pickup built in India with prices starting at $34,500 before on-road costs.
This Mahindra Pik-Up is powered by a 2.2L 4-cylinder engine that has 103 kW of power (at 3750 rpm) and 320 Nm of torque (at 1500 rpm) via a Six-speed Manual transmission. Mahindra claims the Pik-Up S10+ uses 8.8L/100km of Diesel in the combined city and highway cycle while putting out nullg of CO2. It has a 80L fuel tank, meaning it should be able to travel 909km per full tank
The Mahindra Pik-Up measures 1915mm (75.4 inches) in height, 5195mm (204.5 inches) in length, 1820mm (71.7 inches) in width with a 3040mm (119.7 inches) wheelbase that brings about a total of 2080kg (4585.6 lbs) of unladen weight. The Pik-Up S10+ comes standard with 245/75 R16 front tyres and 245/75 R16 rear tyres. It requires a service every 12 months or 15,000 km, whichever comes first. It has a 60 month, 100,000 km warranty.
The 2022 Mahindra Pik-Up S10+ has a 210mm ground clearance with a 2500kg braked and 750kg unbraked towing capacity.
Trusted Reviews, Smarter Choices, Better Prices
Where expert car reviews meet expert car buying – CarExpert gives you trusted advice, personalised service and real savings on your next new car.
How does the Pik-Up compare?
Quickly see how the 2022 Mahindra Pik-Up S10+ stacks up against its competition.
 Select any benchmark to see more details.
Power to Weight
47.8 - 61.31 kW/t
47.8 kW/t
172.44 kW/t
Fuel Efficiency
8.5 - 9.3 L/100km
6.7 L/100km
12.4 L/100km
Vehicle Range
860 - 941 km
658 km
1,159 km
Price
$25,990 - $42,990
$23,740
$219,950
Warranty (Years)
5 years
3 years
10 years
Warranty (Distance)
100,000 km - Unlimited
100,000 km
Unlimited
Service Interval
12 months
6 months
12 months
Towing & Off-Road Capability
Gross Vehicle Weight
3,150 kg
2,700 kg
5,352 kg
Gross Comb. Mass
5,150 kg
4,435 kg
12,837 kg
Braked Towing Capacity
2,500 kg
1,800 kg
6,171 kg
Approach Angle
34°
15.2°
40.7°
Departure Angle
15°
15°
29.2°
Breakover Angle
18°
18°
27°
Ground Clearance Unladen
210 mm
174 mm
300 mm
Payload Capacity
995 - 1,470 kg
693 kg
1,759 kg
Trusted Reviews, Smarter Choices, Better Prices
Where expert car reviews meet expert car buying – CarExpert gives you trusted advice, personalised service and real savings on your next new car.
Dimensions
5,195 mm
1,820 mm
1,915 mm
| Specification | Measurement |
|---|---|
| Overall Length | 5,195 mm |
| Overall Width | 1,820 mm |
| Overall Height | 1,915 mm |
| Wheelbase | 3,040 mm |
| Turning Circle | 13,400 mm |
| Load Capacity | 1,070 mm |
Looking for complete Mahindra Pik-Up size & space specs?
Our Mahindra Pik-Up Exterior and Dimensions Page has every measurement you need to know exactly how this vehicle will fit your driving, garage, or work needs.
Explore Mahindra Pik-Up Features & Specs
Compressor
Compressor: Turbo
Number of Compressors: 1
Electrical System
Voltage: 12
Emission Control Level
Standard Met: EU5
Engine
Bore Engine: 85.0
Engine (cc): 2179
Engine Configuration: In-Line
Engine (L): 2.2
Number of Cylinders: 4
Number of Valves per Cylinder: 4
Stroke Engine: 96.0
Fuel
Generic Primary Fuel Type: Diesel
Minimum Fuel Type: Diesel
Fuel Type: Diesel
Fuel System
Injection Carburetion: Diesel Common Rail
Fuel Tanks
Main Capacity Gal: 21.1
Main Capacity (L): 80
Main Capacity Uk Gallons: 17.6
Main Type: Total
Fuel Consumption
ADR 81/02 Calculated Vehicle Range (km): 909
ADR 81/02 Calculated Vehicle Range (miles): 565
ADR 81/02 Combined (km/L): 11.4
ADR 81/02 Combined (L/100km): 8.8
ADR 81/02 Combined (miles per UK gallon): 32
ADR 81/02 Combined (mpg): 27
ADR 81/02 Standard: Adr 81/02
Fuel Economy
ADR 81/02 (L/100km): 8.8
Power
Maximum Power (hp/PS): 140
Maximum Power (kW): 103
Maximum Torque (Nm): 320
Primary or Secondary Fuel Power Figure: Primary
Rpm For Maximum Power Low: 3750
Rpm For Maximum Torque Low: 1500
Differential Lock
Location: Centre
Drive
Descent Control System: yes
Driven Wheels: 4x4
Four-Wheel Drive Type: Part-Time
Selection: Manual
Dual Range Transmission
2wd High Low Transfer Selection: 2WD
4wd High High Low Transfer Selection: 4wd High
4wd Low High Low Transfer Selection: 4wd Low
Limited Slip Differential
Location: Rear
Rear Type: Mechanical
Transmission
Description: Manual
Low High Gear Ranges: yes
Number of Speeds: 6
Shift Lever Location: Floor
Type: Manual
Disc Brakes
Number of Disc Brakes: 2
Number of Ventilated Disc Brakes: 2
Steering Wheel
Height Adjustment: yes
Type: Synthetic Leather
Suspension
Location: Front
Front Spring Type: Torsion
Front Stabilizer Bar: yes
Front Type: Wishbone
Front Wheel Dependence: Independent
Location: Rear
Rear Spring Type: Leaf
Rear Type: Beam
Rear Wheel Dependence: Rigid
Tires
Front Wheels Tire Load Index: 111
Location: Front
Front Wheels Tire Profile: 75
Front Wheels Tire Type: All Terrain
Front Wheels Tire Width: 245
Rear Wheels Tire Load Index: 111
Rear Wheels Tire Location: Rear
Rear Wheels Tire Profile: 75
Rear Wheels Tire Type: All Terrain
Rear Wheels Tire Width: 245
Wheels
Location: Front
Front Wheels Rim Diameter (In): 16
Front Wheels Rim Type: Alloy
Front Wheels Rim Width (In): 6.5
Location: 1
Location: Rear
Rear Rim Diameter (In): 16
Rear Rim Type: Alloy
Rear Wheels Rim Width (In): 6.5
Body Style
Body Type: Cab Chassis
Cab Type: Double Cab
Local Body Type: Cab Chassis
Roof Type: low
Wheelbase Type: Short
Mud Flaps
Front Mud Flaps Location: Front
Step
Step Location: Side
External Dimensions
Kerb to Kerb Turning Circle (mm): 13400
Front Track (in): 57.1
Front Track (mm): 1450
Ground Clearance Unladen (in): 8.3
Ground Clearance Unladen (mm): 210
Kerb To Kerb Turning Circle (ft): 44.0
Overall Height (in): 75.4
Overall Height (mm): 1915
Overall Length (in): 204.5
Overall Length (mm): 5195
Overall Width (in): 71.7
Overall Width (mm): 1820
Rear Track (in): 57.1
Rear Track (mm): 1450
Wheelbase (in): 119.7
Wheelbase (mm): 3040
Ramp Angles
Approach Angle: 34.0
Break Over Angle: 18.0
Departure Angle: 15.0
Bumpers
Front Bumper Colour: Painted
Location: Front
Doors
Location: Driver
Driver Door Type: Front Hinged
Location: Passenger
Passenger Door Type: Front Hinged
Location: Rear Driver
Rear Driver Door Type: Front Hinged
Location: Rear Passenger
Rear Passenger Door Type: Front Hinged
Headlight Control
Dusk Sensor: yes
Height Adjustment: Manual
Headlights
High Beam Bulb Type: Halogen
Low Beam Bulb Type: Halogen
Lens Type: Ellipsoidal
LED Lights
Location: Day Time Running Lights
Paint
External Colour: White
Type: Gloss
Door Mirrors/Cameras
Driver Door Mirrors/Cameras Colour: Painted
Mirrors/Cameras Location: Driver
Driver Door Mirrors/Cameras Type: Electrically Adjustable
Passenger Door Mirrors/Cameras Colour: Painted
Mirrors/Cameras Location: Passenger
Passenger Door Mirrors/Cameras Type: Electrically Adjustable
Power Windows
Front Electric Windows: Front
Rear Electric Windows: Rear
Rear Side Windows
Location: Driver
Driver Type: Wind-Up
Location: Passenger
Passenger Type: Wind-Up
Windshield Wipers
Intermittent Wipe Windshield Wipers: Automatic
Rain Sensor Windshield Wipers: yes
Weights
Front Axle Weight (kg): 1210
Front Axle Weight (lb): 2668
Gross Trailer Weight Braked (kg): 2500
Gross Trailer Weight Braked (lb): 5512
Gross Trailer Weight Unbraked (kg): 750
Gross Trailer Weight Unbraked (lb): 1653
Gross Train Weight (kg): 5150
Gross Train Weight (lb): 11354
Gross Vehicle Weight (kg): 3150
Gross Vehicle Weight (lb): 6945
Payload Allowance (kg): 1070
Payload Allowance (lb): 2359
Published Kerb Weight (kg): 2080
Published Kerb Weight (lb): 4586
Rear Axle Weight (kg): 1940
Rear Axle Weight (lb): 4277
Tare Weight (kg): 2021
Audio System
Colour Screen: yes
Digital Media Card: yes
In-Dash CD: yes
Radio Type: Am/Fm
Touch Screen: yes
External Connections
USB (Front): yes
Total Front USB Connections: 1
Total Rear USB Connections: 0
Remote Audio Controls
Type: Steering Wheel Mounted
Speakers
Number of Speakers: 4
Bluetooth
Includes Music Streaming: yes
Includes Phone Connection: yes
Mobile Integration
Android Auto: yes
Android Number of Months Subscription: Unlimited
Apple Carplay: yes
Apple Number of Months Subscription: Unlimited
Mirrorlink Months Subscription Included: 0
Other Months Subscription Included: 0
Power Outlet 12V
Location (12V): Front
Location (12V): Rear
USB Charging Port
Location: Front
Number of Ports in Front: 1
Display Screen
Location: Dashboard Centre 1
Dashboard Centre 1 Screen Orientation: Fixed
Dashboard Centre 1 Screen Size (in): 7.00
Dashboard Centre 1 Touch Screen: yes
Floor Covering
Vehicle Cab Compartment: Textile
Luxury Trim
Doors: Carbon Fibre Look
Instrument Panel: Carbon Fibre Look
Airbags
Number of Airbags: 2
Crash Test Results
ANCAP Date Tested: 20120101
ANCAP Overall: 3.0
ANCAP Pedestrian: Poor
ANCAP Rating Year: 2012
ANCAP Standard: Ancap
ANCAP Version Tested: 2.2 Dual Cab 4x4
Front Airbag
Location: Driver
Location: Passenger
Front Seat Belts
Driver Pre Tensioners: yes
Driver Seat Position: Driver
Passenger Pre Tensioners: yes
Passenger Seat Position: Passenger
Head Restraints
Front Seats Location: Front Seats
Rear Seats Location: Rear Seats
Rear Seats Number: 3
Rear Seat Belts
Center Seat Position: Centre
Center Type: 3-Point
Driver Seat Position: Driver
Passenger Seat Position: Passenger
Front Seat
Driver Front Seat Height Type: Manual
Location: Driver
Driver Front Seat Reach Type: Manual
Driver Front Seat Reclining Type: Manual
Driver Front Seat Type: Bucket
Location: Passenger
Passenger Front Seat Reach Type: Manual
Passenger Front Seat Reclining Type: Manual
Passenger Front Seat Type: Bucket
Seat Upholstery
Additional Seat Material: Cloth
Main Seat Material: Cloth
Seating
Capacity: 5
Configuration: 2+3
Cup Holders
Location: Front Seats
Air Conditioning
Type: Fully-Auto
Ventilation System
Digital Display: yes
Power Locks
Operation: Remote
Intermediate Service
Distance (km): 15000
Distance (miles): 9321
Period (Months): 12
