Base
Overview
The 2009 Mercedes-Benz CLS-Class Base is a rear-wheel drive, 4-door Sedan that was released to the Australian market on 4th January 1970. The Mercedes-Benz CLS-Class is regarded as a large Car built in Germany with prices starting at $193,500 before on-road costs.
This Mercedes-Benz CLS-Class is powered by a 5.5L 8-cylinder engine that has 285 kW of power (at 6000 rpm) and 530 Nm of torque (at 2800 rpm) via a Seven-speed Automatic transmission. Mercedes-Benz claims the CLS Base uses 12.8L/100km of Premium Unleaded in the combined city and highway cycle while putting out 305g of CO2. It has a 80L fuel tank, meaning it should be able to travel 625km per full tank
The Mercedes-Benz CLS-Class measures 1390mm (54.7 inches) in height, 4910mm (193.3 inches) in length, 1873mm (73.7 inches) in width with a 2854mm (112.4 inches) wheelbase that brings about a total of 1810kg (3990.4 lbs) of unladen weight. The CLS Base comes standard with 245/35 R18 front tyres and 275/35 R18 rear tyres. It has a 36 month, unlimited km warranty.
How does the CLS compare?
Quickly see how the 2009 Mercedes-Benz CLS-Class Base stacks up against its competition.
 Select any benchmark to see more details.
Power to Weight
115.27 - 198.43 kW/t
75.88 kW/t
212.54 kW/t
Boot Space
495 - 505 litres
495 litres
690 litres
Fuel Efficiency
11 - 14.5 L/100km
5.6 L/100km
14.8 L/100km
Vehicle Range
552 - 727 km
473 km
1,067 km
Warranty (Years)
3 years
3 years
Warranty (Distance)
Unlimited
100,000 km
Unlimited
Dimensions
4,910 mm
1,873 mm
1,390 mm
| Specification | Measurement |
|---|---|
| Overall Length | 4,910 mm |
| Overall Width | 1,873 mm |
| Overall Height | 1,390 mm |
| Wheelbase | 2,854 mm |
| Turning Circle | 11,200 mm |
Looking for complete Mercedes-Benz CLS-Class size & space specs?
Our Mercedes-Benz CLS-Class Exterior and Dimensions Page has every measurement you need to know exactly how this vehicle will fit your driving, garage, or work needs.
Explore Mercedes-Benz CLS-Class Features & Specs
Bluetooth
Type: Bluetooth
Cruise Control
Speed Limiter: yes
Steering Wheel Mounted Controls: yes
Entertainment Display Screen
Location: Front
Front TV: yes
Memorised Adjustment
Door Mirror Position: yes
Number of Memorised Driver Seat Positions: 4
Number of Memorised Passenger Seat Positions: 4
Parking Distance System
Location: Front
Front Type: Sensor
Location: Rear
Rear Type: Sensor
Power Outlet 12V
Location (12V): Front
Smart Card/Smart Key
Includes Keyless Entry: yes
Includes Keyless Start: yes
Includes Memory Seat Adjustments: yes
Includes Memory Steering Wheel Position: yes
Includes Radio Settings: yes
Type: Automatic
Vanity Mirror
Driver Mirror Illuminated: yes
Driver Mirror Location: Driver
Passenger Mirror Illuminated: yes
Location: Passenger
Voice Activating System
Includes Audio Player: yes
Includes Navigation System: yes
Includes Phone: yes
Emission Control Level
Australia Air Pollution Rating: 6.5
Australia Greenhouse Rating: 3.5
Australia Overall Emission Control Level Rating: 3.0
CO2 Level (Combined): 305
Standard Met: EU4
Engine
Bore Engine: 98.0
Engine (cc): 5461
Engine Configuration: V
Engine (L): 5.5
Number of Cylinders: 8
Number of Valves per Cylinder: 4
Stroke Engine: 90.5
Valve Gear Type: Double Overhead Cam
Variable Valve Timing Camshaft: yes
Fuel
Generic Primary Fuel Type: Petrol
Minimum Fuel Octane Number: 95
Minimum Fuel Type: Premium Unleaded
Fuel Type: Premium Unleaded
Octane Number: 95
Fuel System
Injection Carburetion: Multi-Point Injection
Fuel Tanks
Main Capacity Gal: 21.1
Main Capacity (L): 80
Main Capacity Uk Gallons: 17.6
Main Fuel Type: Premium Unleaded
Main Type: Total
Computer
Average Fuel Consumption: yes
Average Speed: yes
Range for Remaining Fuel: yes
Fuel Consumption
ADR 81/02 Calculated Vehicle Range (km): 625
ADR 81/02 Calculated Vehicle Range (miles): 388
ADR 81/02 Combined (km/L): 7.8
ADR 81/02 Combined (L/100km): 12.8
ADR 81/02 Combined (miles per UK gallon): 22
ADR 81/02 Combined (mpg): 18
ADR 81/02 Country Highway (km/L): 10.8
ADR 81/02 Country Highway (L/100km): 9.3
ADR 81/02 Country Highway (miles per UK gallon): 30
ADR 81/02 Country Highway (mpg): 25
ADR 81/02 Standard: Adr 81/02
ADR 81/02 Urban (km/L): 5.3
ADR 81/02 Urban (L/100km): 18.9
ADR 81/02 Urban (miles per UK gallon): 15
ADR 81/02 Urban (mpg): 12
Fuel Economy
ADR 81/02 (L/100km): 12.8
Performance
Acceleration 0 To 100 km/h: 5.4
Maximum Speed (km/h): 250
Maximum Speed (mph): 155
Power
Maximum Power (hp/PS): 388
Maximum Power (kW): 285
Maximum Torque (Nm): 530
Measurement Standard: EEC
Rpm For Maximum Power Low: 6000
Rpm For Maximum Torque Low: 2800
Drive
Driven Wheels: Rear
Electronic Traction Control
Controlled By: Abs & Engine Management
Transmission
Description: Automatic With Manual Mode
Manual Mode: yes
Number of Speeds: 7
Shift Lever Location: Steering Wheel
Type: Automatic
Disc Brakes
Number of Disc Brakes: 4
Number of Ventilated Disc Brakes: 4
Power Steering
Vehicle Speed Proportional: yes
Steering Wheel
Electric Adjustment: yes
Height Adjustment: yes
Telescopic Adjustment: yes
Type: Leather Covered
Suspension
Location: Front
Front Spring Type: air
Front Stabilizer Bar: yes
Front Type: Wishbone
Front Wheel Dependence: Independent
Location: Rear
Rear Spring Type: air
Rear Stabilizer Bar: yes
Rear Type: Multi-Link
Rear Wheel Dependence: Independent
Suspension Levelling
Location: Front
Front Operation: Automatic
Location: Rear
Rear Operation: Automatic
Tires
Location: Front
Front Wheels Tire Profile: 40
Front Wheels Tire Speed Rating: Z
Front Wheels Tire Type: Conventional/Summer
Front Wheels Tire Width: 245
Rear Wheels Tire Location: Rear
Rear Wheels Tire Profile: 35
Rear Wheels Tire Speed Rating: Z
Rear Wheels Tire Type: Conventional/Summer
Rear Wheels Tire Width: 275
Wheels
Location: Front
Front Wheels Rim Diameter (In): 18
Front Wheels Rim Type: Alloy
Front Wheels Rim Width (In): 8.5
Location: Rear
Rear Rim Diameter (In): 18
Rear Rim Type: Alloy
Rear Wheels Rim Width (In): 9.5
Body Style
Body Type: Sedan
Local Body Type: Sedan
Spoiler
Front Spoiler Colour: Body Colour
Location: Front
Front Spoiler Type: lip
Underbody Protection
Location: Engine
Bumpers
Front Bumper Colour: Painted
Location: Front
Rear Bumper Colour: Painted
Location: Rear
Cargo Capacity
Rear Seat Up to Lower Window (cu ft): 17.5
Rear Seat Up to Lower Window (L): 495
External Dimensions
Kerb to Kerb Turning Circle (mm): 11200
Front Track (in): 62.7
Front Track (mm): 1593
Kerb To Kerb Turning Circle (ft): 36.7
Overall Height (in): 54.7
Overall Height (mm): 1390
Overall Length (in): 193.3
Overall Length (mm): 4910
Overall Width (in): 73.7
Overall Width (mm): 1873
Rear Track (in): 63.1
Rear Track (mm): 1603
Wheelbase (in): 112.4
Wheelbase (mm): 2854
Internal Dimensions
Front Headroom (in): 38.4
Front Headroom (mm): 975
Rear Headroom (in): 36.4
Rear Headroom (mm): 924
Front Hip Room (in): 58.0
Front Hip Room (mm): 1472
Rear Hip Room (in): 57.6
Rear Hip Room (mm): 1464
Front Shoulder Room (in): 56.3
Front Shoulder Room (mm): 1429
Rear Shoulder Room (in): 56.0
Rear Shoulder Room (mm): 1422
Doors
Location: Driver
Driver Door Type: Front Hinged
Location: Passenger
Passenger Door Type: Front Hinged
Location: Rear Driver
Rear Driver Door Type: Front Hinged
Location: Rear Passenger
Rear Passenger Door Type: Front Hinged
Headlight Control
Directional Headlights: yes
Dusk Sensor: yes
Internal Height Adjustment: yes
Headlights
Low Beam Bulb Type: Bi-Xenon
Paint
External Colour: Black
Type: Metallic
Sunroof
Front Sunroof Location: Front
Front Sunroof Operation: Electric
Front Sunroof Type: Glass
Blind
Location: Rear
Rear Blind Type: Electric
Door Mirrors/Cameras
Driver Door Mirrors/Cameras Colour: Painted
Mirrors/Cameras Location: Driver
Driver Door Mirrors/Cameras Type: Electrically Adjustable
Passenger Door Mirrors/Cameras Colour: Painted
Mirrors/Cameras Location: Passenger
Passenger Door Mirrors/Cameras Type: Electrically Adjustable
Electrically Foldable Mirrors
Operation: Electric
Heat Reflective Glass
Location: ?
Power Windows
Front Electric Windows: Front
Rear Electric Windows: Rear
Rear View Mirror Camera
Auto Dimming: yes
Windshield Wipers
Intermittent Wipe Windshield Wipers: Automatic
Rain Sensor Windshield Wipers: yes
Weights
Gross Trailer Weight Braked (kg): 0
Gross Trailer Weight Braked (lb): 0
Gross Trailer Weight Unbraked (kg): 0
Gross Trailer Weight Unbraked (lb): 0
Published Kerb Weight (kg): 1810
Published Kerb Weight (lb): 3990
Audio System
CD Player Reads MP3: yes
Digital Media Card: yes
Disc Autochanger: yes
Autochanger Disc Capacity: 6
Radio Type: Am/Fm
Disc Player
Dashboard Capacity: 6
Location: Dashboard
Dashboard Media Type: DVD
External Connections
Aux Jack (Front): yes
iPod Connection (Front): yes
USB (Front): yes
Remote Audio Controls
Type: Steering Wheel Mounted
Speakers
Number of Speakers: 12
Luxury Trim
Centre Floor Console: Wood Or Woodlook
Doors: Leather
Gear Selector: Leather
Instrument Panel: Wood Or Woodlook
Front Airbag
Location: Driver
Location: Passenger
Front Seat Belts
Driver Height Adjustable: yes
Driver Operation: Reel
Driver Pre Tensioners: yes
Driver Seat Position: Driver
Driver Type: 3-Point
Passenger Height Adjustable: yes
Passenger Operation: Reel
Passenger Pre Tensioners: yes
Passenger Seat Position: Passenger
Passenger Type: 3-Point
Head Restraints
Front Seats Active: yes
Front Seats Electric Adjustable: yes
Front Seats Location: Front Seats
Rear Seats Location: Rear Seats
Rear Seats Number: 2
Rear Seat Belts
Driver Operation: Reel
Driver Seat Position: Driver
Driver Type: 3-Point
Passenger Operation: Reel
Passenger Seat Position: Passenger
Passenger Type: 3-Point
Side Airbag
Location: Front
Location: Rear
Side Curtain Airbag
Location: Front And Rear
Front Seat
Driver Front Seat Active Massage: yes
Driver Front Seat Power Adjustable: yes
Driver Front Seat Heated: yes
Driver Front Seat Height Adjustment: yes
Location: Driver
Driver Front Seat Lumbar Adjustment: yes
Driver Front Seat Number of Electrical Adjustments: 5
Driver Front Seat Type: Bucket
Passenger Front Seat Active Massage: yes
Passenger Front Seat Power Adjustable: yes
Passenger Front Seat Heated: yes
Passenger Front Seat Height Adjustment: yes
Location: Passenger
Passenger Front Seat Lumbar Adjustment: yes
Passenger Front Seat Number of Electrical Adjustments: 5
Passenger Front Seat Type: Bucket
Passenger Front Seat Ventilated: yes
Seat Upholstery
Additional Seat Material: Leather
Main Seat Material: Leather
Seating
Capacity: 4
Configuration: 2+2
Cup Holders
Location: Front Seats
Location: Rear Seats
Air Conditioning
Climate Control - Number of Zones: 4
Fully Automated Climate Control: yes
Rear Control For Climate Control: yes
Secondary Ventilation Controls
Passenger Seat Location: Passenger Seat
Rear Seats Location: Rear Seats
Ventilation System
Digital Display: yes
Anti-Theft Protection
Anti-Lift: yes
Interior Monitoring: yes
Peripheral: yes
Remote Operation: yes
Power Locks
Includes Trunk Hatch: yes
Operation: Remote
