Base
2.1L, 6-speed manual, 4-door Panel Van, Diesel, 4x4
Save $$$ with CarExpert*
$88,060â€
Base
Overview
The 2018 Mercedes-Benz Sprinter Base is a four-wheel drive, 4-door Panel Van that was released to the Australian market on 4th October 2013. The Mercedes-Benz Sprinter is regarded as a Van Over 3.5t built in Germany with prices starting at $88,060 before on-road costs.
This Mercedes-Benz Sprinter is powered by a 2.1L 4-cylinder engine that has 95 kW of power (at 3800 rpm) and 305 Nm of torque (at 1200 rpm) via a Six-speed Manual transmission. It has a 100L fuel tank
It requires a service every 12 months or 30,000 km, whichever comes first. It has a 36 month, 200,000 km warranty.
Trusted Reviews, Smarter Choices, Better Prices
Where expert car reviews meet expert car buying – CarExpert gives you trusted advice, personalised service and real savings on your next new car.
How does the Sprinter compare?
Quickly see how the 2018 Mercedes-Benz Sprinter Base stacks up against its competition.
 Select any benchmark to see more details.
Power to Weight
32.51 - 66.67 kW/t
32.51 kW/t
75 kW/t
Price
$44,490 - $97,955
$43,490
$97,955
Warranty (Years)
3 years
3 years
5 years
Warranty (Distance)
200,000 km
200,000 km
Unlimited
Years on Sale
2 - 8 years
1 year
5 years
Service Interval
12 months
12 months
Trusted Reviews, Smarter Choices, Better Prices
Where expert car reviews meet expert car buying – CarExpert gives you trusted advice, personalised service and real savings on your next new car.
Dimensions
6,961 mm
1,993 mm
| Specification | Measurement |
|---|---|
| Overall Length | 6,961 mm |
| Overall Width | 1,993 mm |
| Wheelbase | 4,325 mm |
| Turning Circle | 14,600 mm |
| Load Capacity | 1,783 mm |
Looking for complete Mercedes-Benz Sprinter size & space specs?
Our Mercedes-Benz Sprinter Exterior and Dimensions Page has every measurement you need to know exactly how this vehicle will fit your driving, garage, or work needs.
Sales Data
Mercedes-Benz Sprinter Sales rolling 12-months#
Explore Mercedes-Benz Sprinter Features & Specs
Compressor
Compressor: Turbo
Emission Control Level
Standard Met: EU5
Engine
Bore Engine: 83.0
Engine (cc): 2143
Engine Configuration: In-Line
Engine Code: Om 651 De22la
Engine (L): 2.1
Number of Cylinders: 4
Number of Valves per Cylinder: 4
Stroke Engine: 99.0
Fuel
Generic Primary Fuel Type: Diesel
Minimum Fuel Type: Diesel
Fuel Type: Diesel
Fuel System
Injection Carburetion: Diesel Common Rail
Fuel Tanks
Main Capacity Gal: 26.4
Main Capacity (L): 100
Main Capacity Uk Gallons: 22.0
Main Type: Total
Interested in buying a Mercedes-Benz Sprinter Base?
Save $$$ with CarExpert*
From
$88,060â€
Fuel Consumption
ADR 81/02 Standard: Adr 81/02
Power
Maximum Power (hp/PS): 129
Maximum Power (kW): 95
Maximum Torque (Nm): 305
Measurement Standard: EEC
Primary or Secondary Fuel Power Figure: Primary
Rpm For Maximum Power Low: 3800
Rpm For Maximum Torque Low: 1200
Drive
Driven Wheels: 4x4
Four-Wheel Drive Type: Full-Time
Transmission
Description: Manual
Number of Speeds: 6
Type: Manual
Disc Brakes
Number of Disc Brakes: 4
Number of Ventilated Disc Brakes: 2
Power Steering
Type: Hydraulic
Steering Wheel
Height Adjustment: yes
Telescopic Adjustment: yes
Type: Plastic
Alternate Suspension
Type: Heavy Duty
Suspension
Location: Front
Front Spring Type: Leaf
Front Stabilizer Bar: yes
Front Type: Wishbone
Front Wheel Dependence: Independent
Location: Rear
Rear Spring Type: Leaf
Rear Stabilizer Bar: yes
Rear Type: Beam
Rear Wheel Dependence: Rigid
Tires
Front Wheels Tire Load Index: 107
Location: Front
Front Wheels Tire Low Rolling Resistance: yes
Front Wheels Tire Profile: 75
Front Wheels Tire Type: Conventional/Summer
Front Wheels Tire Width: 195
Rear Wheels Tire Load Index: 107
Rear Wheels Tire Location: Rear
Rear Wheels Tire Low Rolling Resistance: yes
Rear Wheels Tire Profile: 75
Rear Wheels Tire Type: Conventional/Summer
Rear Wheels Tire Width: 195
Wheels
Location: Front
Front Wheels Rim Diameter (In): 16
Front Wheels Rim Type: Steel
Front Wheels Rim Width (In): 5.5
Location: 1
Rear Axle 1 Dual Wheel: yes
Location: Rear
Rear Rim Diameter (In): 16
Rear Rim Type: Steel
Rear Wheels Rim Width (In): 5.5
Body Style
Body Type: Panel Van
Local Body Type: Panel Van
Platform Code: Ncv3
Roof Type: Extra-High
Wheelbase Type: Long
Mud Flaps
Front Mud Flaps Location: Front
Rear Mud Flaps Location: Rear
Step
Step Location: Rear
Rear Step Type: Platform
Bumpers
Front Bumper Colour: Black
Location: Front
Rear Bumper Colour: Black
Location: Rear
Cargo Area Dimensions
Cargo Volume (cu ft): 529.7
Cargo Volume (L): 15000
Height (in): 84.3
Height (mm): 1780
Length (in): 169.3
Length (mm): 4300
Loading Floor Height (in): 29.9
Loading Floor Height (mm): 760
Standard Measurement: VDA
Width Between Wheelhouses (in): 38.5
Width Between Wheelhouses (mm): 978
Width (in): 70.1
Width (mm): 1780
External Dimensions
Kerb to Kerb Turning Circle (mm): 14600
Kerb To Kerb Turning Circle (ft): 47.9
Overall Length (in): 274.1
Overall Length (mm): 6961
Overall Width (in): 78.5
Overall Width (mm): 1993
Rear Overhang (in): 63.6
Rear Overhang (mm): 1615
Rear Track (in): 61.6
Rear Track (mm): 1565
Wall to Wall Turning Circle (ft): 51.2
Wall to Wall Turning Circle (mm): 15600
Wheelbase (in): 170.3
Wheelbase (mm): 4325
Cargo Doors
Driver Internal Handles: yes
Driver Location: Driver
Driver Opening Angle: 0
Driver Operation: Sliding
Passenger Height (in): 71.7
Passenger Height (mm): 1820
Location: Passenger
Passenger Operation: Sliding
Passenger Width (in): 51.2
Passenger Width (mm): 1300
Rear Height (in): 72.4
Rear Height (mm): 1840
Rear Internal Handles: yes
Location: Rear
Rear Opening Angle: 180
Rear Operation: Double Hinged
Rear Width (in): 61.6
Rear Width (mm): 1565
Doors
Location: Driver
Driver Door Type: Front Hinged
Location: Passenger
Passenger Door Type: Front Hinged
Headlight Control
Auto Highbeam: yes
Directional Headlights: yes
Height Adjustment: Manual
Internal Height Adjustment: yes
Headlights
High Beam Bulb Type: Halogen
Low Beam Bulb Type: Halogen
Lens Type: Complex Surface
Paint
External Colour: White
Type: Gloss
Door Mirrors/Cameras
Driver Door Mirrors/Cameras Colour: Black
Mirrors/Cameras Location: Driver
Driver Door Mirrors/Cameras Type: Electrically Adjustable
Passenger Door Mirrors/Cameras Colour: Black
Mirrors/Cameras Location: Passenger
Passenger Door Mirrors/Cameras Type: Electrically Adjustable
Power Windows
Front Electric Windows: Front
Rear Side Windows
Location: Driver
Driver Type: Fixed
Location: Passenger
Passenger Type: Fixed
Third Row Windows
Location: Driver
Driver Type: Fixed
Location: Passenger
Passenger Type: Fixed
Tinted Glass
Location: Rear
Location: Side
Windshield Wipers
Intermittent Wipe Windshield Wipers: Fixed
Weights
Front Axle Weight (kg): 2000
Front Axle Weight (lb): 4409
Gross Trailer Weight Braked (kg): 2000
Gross Trailer Weight Braked (lb): 4409
Gross Trailer Weight Unbraked (kg): 750
Gross Trailer Weight Unbraked (lb): 1653
Gross Train Weight (kg): 6490
Gross Train Weight (lb): 14308
Gross Vehicle Weight (kg): 4490
Gross Vehicle Weight (lb): 9899
Payload Allowance (kg): 1783
Payload Allowance (lb): 3931
Published Kerb Weight (kg): 2707
Published Kerb Weight (lb): 5968
Rear Axle Weight (kg): 3500
Rear Axle Weight (lb): 7716
Tare Weight (kg): 2631
Audio System
Colour Screen: yes
Digital Media Card: yes
Radio Type: Am/Fm
External Connections
Aux Jack (Front): yes
iPod Connection (Front): yes
USB (Front): yes
Remote Audio Controls
Type: Steering Wheel Mounted
Speakers
Number of Speakers: 2
Bulkhead
Type: Solid
Solid Bulkhead Window: yes
Bluetooth
Includes Music Streaming: yes
Includes Phone Connection: yes
Parking Distance System
Location: Front
Front Type: Sensor
Location: Rear
Rear Type: Sensor
Power Outlet 12V
Location (12V): Boot/Cargo
Location (12V): Front
Smart Card/Smart Key
Includes Keyless Entry: yes
Type: Automatic
Display Screen
Location: Instrument Cluster 1
Instrument Cluster 1 Screen Size (in): 5.8
Floor Covering
Load Area: Wood
Vehicle Cab Compartment: Plastic/Rubber
Airbags
Number of Airbags: 2
Front Airbag
Location: Driver
Location: Passenger
Front Seat Belts
Driver Height Adjustable: yes
Driver Pre Tensioners: yes
Driver Seat Position: Driver
Passenger Height Adjustable: yes
Passenger Pre Tensioners: yes
Passenger Seat Position: Passenger
Head Restraints
Front Seats Location: Front Seats
Rear Seats Location: Rear Seats
Rear Seats Number: 3
Rear Seats Type: Cushion
Overtaking Sensor
Manufacturer Name: Blind Spot Assist
Rear Seat Belts
Center Operation: Reel
Center Seat Position: Centre
Center Type: 3-Point
Driver Operation: Reel
Driver Seat Position: Driver
Driver Type: 3-Point
Passenger Operation: Reel
Passenger Seat Position: Passenger
Passenger Type: 3-Point
Side Airbag
Location: Front
Side Curtain Airbag
Location: Front
Front Seat
Driver Front Seat Height Adjustment: yes
Driver Front Seat Height Type: Manual
Location: Driver
Driver Front Seat Lumbar Adjustment: yes
Driver Front Seat Reach Type: Manual
Driver Front Seat Seat Suspension: Mechanical
Driver Front Seat Type: Bucket
Passenger Front Seat Height Adjustment: yes
Location: Passenger
Passenger Front Seat Lumbar Adjustment: yes
Passenger Front Seat Reach Type: Manual
Passenger Front Seat Seat Suspension: Mechanical
Passenger Front Seat Type: Bucket
Front Seat Center Armrest
Center Front Seat Armrest Adjustable: yes
Center Front Seat Armrest Folding: yes
Seat Upholstery
Additional Seat Material: Cloth
Main Seat Material: Cloth
Seating
Capacity: 2
Configuration: 2+0
Cup Holders
Location: Front Seats
Air Conditioning
Type: Fully-Auto
Power Locks
Operation: Remote
Intermediate Service
Distance (km): 30000
Distance (miles): 18641
Period (Months): 12
