Nissan Navara N-Sport Black Edition (2017) price & specs
Save $$$ with CarExpert*
From
$54,490†
N-Sport Black Edition
Overview
The 2017 Nissan Navara N-Sport Black Edition is a four-wheel drive, 4-door Utility that was released to the Australian market on 1st January 2018 classified as a D23 Series 2. The Nissan Navara is regarded as a Pickup built in Spain with prices starting at $54,490 before on-road costs.
This Nissan Navara is powered by a 2.3L 4-cylinder engine that has 140 kW of power (at 3750 rpm) and 450 Nm of torque (at 1500 rpm) via a Six-speed Manual transmission. Nissan claims the Navara N-Sport Black Edition uses 6.5L/100km of Diesel in the combined city and highway cycle while putting out 172g of CO2. It has a 80L fuel tank, meaning it should be able to travel 1231km per full tank
The Nissan Navara measures 1840mm (72.4 inches) in height, 5255mm (206.9 inches) in length, 1850mm (72.8 inches) in width with a 3150mm (124.0 inches) wheelbase that brings about a total of 1963kg (4327.7 lbs) of unladen weight. The Navara N-Sport Black Edition comes standard with 255/60 R18 front tyres and 255/60 R18 rear tyres. It requires a service every 12 months or 20,000 km, whichever comes first. It has a 36 month, 100,000 km warranty.
The 2017 Nissan Navara N-Sport Black Edition has a 228mm ground clearance with a 3500kg braked and 750kg unbraked towing capacity.
Trusted Reviews, Smarter Choices, Better Prices
Where expert car reviews meet expert car buying – CarExpert gives you trusted advice, personalised service and real savings on your next new car.
How does the Navara compare?
Quickly see how the 2017 Nissan Navara N-Sport Black Edition stacks up against its competition.
Select any benchmark to see more details.
Power to Weight
63.63 - 92.28 kW/t
53.42 kW/t
92.28 kW/t
Fuel Efficiency
6.3 - 9.9 L/100km
6.3 L/100km
10.9 L/100km
Vehicle Range
808 - 1,270 km
688 km
1,270 km
Price
$19,490 - $56,990
$19,490
$149,500
Warranty (Years)
3 years
2 years
5 years
Warranty (Distance)
100,000 km
100,000 km
Unlimited
Years on Sale
2 - 6 years
1 year
4 years
Service Interval
12 months
6 months
12 months
Towing & Off-Road Capability
Gross Vehicle Weight
2,550 - 2,910 kg
2,550 kg
4,490 kg
Gross Comb. Mass
4,138 - 5,910 kg
4,138 kg
11,479 kg
Braked Towing Capacity
1,588 - 3,500 kg
1,588 kg
6,942 kg
Approach Angle
29.5 - 32.5°
20.7°
35°
Departure Angle
23 - 26.7°
20.3°
29°
Ground Clearance Unladen
191 - 230 mm
188 mm
279 mm
Payload Capacity
880 - 1,359 kg
864 kg
1,533 kg
Trusted Reviews, Smarter Choices, Better Prices
Where expert car reviews meet expert car buying – CarExpert gives you trusted advice, personalised service and real savings on your next new car.
Dimensions
5,255 mm
1,850 mm
1,840 mm
| Specification | Measurement |
|---|---|
| Overall Length | 5,255 mm |
| Overall Width | 1,850 mm |
| Overall Height | 1,840 mm |
| Wheelbase | 3,150 mm |
| Turning Circle | 12,400 mm |
| Load Capacity | 947 mm |
Looking for complete Nissan Navara size & space specs?
Our Nissan Navara Exterior and Dimensions Page has every measurement you need to know exactly how this vehicle will fit your driving, garage, or work needs.
Sales Data
Nissan Navara Sales rolling 12-months#
Explore Nissan Navara Features & Specs
Compressor
Compressor: Turbo
Number of Compressors: 2
Emission Control Level
CO2 Level (Combined): 172
Standard Met: EU5
Engine
Bore Engine: 85.0
Engine (cc): 2298
Engine Configuration: In-Line
Engine Code: Ys23ddtt
Engine (L): 2.3
Number of Cylinders: 4
Number of Valves per Cylinder: 4
Stroke Engine: 101.3
Fuel
Generic Primary Fuel Type: Diesel
Minimum Fuel Type: Diesel
Fuel Type: Diesel
Fuel System
Injection Carburetion: Diesel Common Rail
Fuel Tanks
Main Capacity Gal: 21.1
Main Capacity (L): 80
Main Capacity Uk Gallons: 17.6
Main Type: Total
Interested in buying a Nissan Navara N-Sport Black Edition?
Save $$$ with CarExpert*
From
$54,490†
Fuel Consumption
ADR 81/02 Calculated Vehicle Range (km): 1231
ADR 81/02 Calculated Vehicle Range (miles): 765
ADR 81/02 Combined (km/L): 15.4
ADR 81/02 Combined (L/100km): 6.5
ADR 81/02 Combined (miles per UK gallon): 44
ADR 81/02 Combined (mpg): 36
ADR 81/02 Country Highway (km/L): 16.7
ADR 81/02 Country Highway (L/100km): 6.0
ADR 81/02 Country Highway (miles per UK gallon): 47
ADR 81/02 Country Highway (mpg): 39
ADR 81/02 Standard: Adr 81/02
ADR 81/02 Urban (km/L): 13.5
ADR 81/02 Urban (L/100km): 7.4
ADR 81/02 Urban (miles per UK gallon): 38
ADR 81/02 Urban (mpg): 32
Fuel Economy
ADR 81/02 (L/100km): 6.5
Power
Maximum Power (hp/PS): 190
Maximum Power (kW): 140
Maximum Torque (Nm): 450
Measurement Standard: EEC
Primary or Secondary Fuel Power Figure: Primary
Rpm For Maximum Power Low: 3750
Rpm For Maximum Torque Low: 1500
Differential Lock
Location: Rear
Drive
Descent Control System: yes
Driven Wheels: 4x4
Four-Wheel Drive Type: Part-Time
Selection: Manual
Transmission
Code: Fs6r31a
Description: Manual
Low High Gear Ranges: yes
Number of Speeds: 6
Type: Manual
Disc Brakes
Number of Disc Brakes: 2
Number of Ventilated Disc Brakes: 2
Steering Wheel
Height Adjustment: yes
Type: Alloy & Leather
Suspension
Location: Front
Front Spring Type: Coil
Front Stabilizer Bar: yes
Front Type: Wishbone
Front Wheel Dependence: Independent
Location: Rear
Rear Spring Type: Coil
Rear Type: Multi-Link
Rear Wheel Dependence: Independent
Tires
Front Wheels Tire Load Index: 112
Location: Front
Front Wheels Tire Profile: 60
Front Wheels Tire Speed Rating: S
Front Wheels Tire Type: Conventional/Summer
Front Wheels Tire Width: 255
Rear Wheels Tire Load Index: 112
Rear Wheels Tire Location: Rear
Rear Wheels Tire Profile: 60
Rear Wheels Tire Speed Rating: S
Rear Wheels Tire Type: Conventional/Summer
Rear Wheels Tire Width: 255
Wheels
Location: Front
Front Wheels Rim Diameter (In): 18
Front Wheels Rim Type: Alloy
Front Wheels Rim Width (In): 7.0
Front Wheels Two Tone: yes
Location: 1
Location: Rear
Rear Rim Diameter (In): 18
Rear Rim Type: Alloy
Rear Wheels Rim Width (In): 7.0
Rear Two Tone: yes
Body Style
Body Type: Utility
Cab Type: Double Cab
Local Body Type: Utility
Platform Code: F Alpha
Roof Type: Standard
Wheelbase Type: Short
Mud Flaps
Front Mud Flaps Location: Front
Rear Mud Flaps Location: Rear
Spoiler
Location: Boot/Hatch
Step
Step Location: Rear
Rear Step Type: Platform
Step Location: Side
Brush Guard
Type: Rigid
Bumpers
Front Bumper Colour: Painted
Location: Front
Rear Bumper Colour: Painted
Location: Rear
Tray/Tub
Liner: Composite
Cover: Tonneau Cover
Type: Straight Side
Cargo Area Dimensions
Height (in): 18.7
Height (mm): 1560
Length (in): 59.2
Length (mm): 1503
Loading Floor Height (in): 32.1
Loading Floor Height (mm): 815
Standard Measurement: Manufacturer'S Own
Width Between Wheelhouses (in): 44.5
Width Between Wheelhouses (mm): 1130
Width (in): 61.4
Width (mm): 1560
External Dimensions
Kerb to Kerb Turning Circle (mm): 12400
Front Overhang (in): 34.3
Front Overhang (mm): 870
Front Track (in): 61.8
Front Track (mm): 1570
Ground Clearance Unladen (in): 9.0
Ground Clearance Unladen (mm): 228
Kerb To Kerb Turning Circle (ft): 40.7
Overall Height (in): 72.4
Overall Height (mm): 1840
Overall Length (in): 206.9
Overall Length (mm): 5255
Overall Width (in): 72.8
Overall Width (mm): 1850
Rear Overhang (in): 48.6
Rear Overhang (mm): 1235
Rear Track (in): 61.8
Rear Track (mm): 1570
Wheelbase (in): 124.0
Wheelbase (mm): 3150
Ramp Angles
Approach Angle: 32.4
Departure Angle: 26.7
Cargo Doors
Rear Height (in): 18.7
Rear Height (mm): 474
Location: Rear
Rear Opening Angle: 90
Rear Operation: Dropping Gate
Rear Width (in): 56.4
Rear Width (mm): 1432
Doors
Location: Driver
Driver Door Type: Front Hinged
Location: Passenger
Passenger Door Type: Front Hinged
Location: Rear Driver
Rear Driver Door Type: Front Hinged
Location: Rear Passenger
Rear Passenger Door Type: Front Hinged
Headlight Control
Dusk Sensor: yes
Height Adjustment: Automatic
Headlights
High Beam Bulb Type: LED
Low Beam Bulb Type: LED
Lens Type: Complex Surface
LED Lights
Location: Day Time Running Lights
Paint
External Colour: Black
Type: Gloss
Door Mirrors/Cameras
Driver Door Mirrors/Cameras Colour: Chrome
Mirrors/Cameras Location: Driver
Driver Door Mirrors/Cameras Type: Electrically Adjustable
Passenger Door Mirrors/Cameras Colour: Chrome
Mirrors/Cameras Location: Passenger
Passenger Door Mirrors/Cameras Type: Electrically Adjustable
Power Windows
Front Electric Windows: Front
Rear Electric Windows: Rear
Rear Side Windows
Location: Driver
Driver Type: Wind-Up
Location: Passenger
Passenger Type: Wind-Up
Rear View Mirror Camera
Auto Dimming: yes
Windshield Wipers
Intermittent Wipe Windshield Wipers: Automatic
Weights
Front Axle Weight (kg): 1320
Front Axle Weight (lb): 2910
Gross Trailer Weight Braked (kg): 3500
Gross Trailer Weight Braked (lb): 7716
Gross Trailer Weight Unbraked (kg): 750
Gross Trailer Weight Unbraked (lb): 1653
Gross Train Weight (kg): 5910
Gross Train Weight (lb): 13029
Gross Vehicle Weight (kg): 2910
Gross Vehicle Weight (lb): 6415
Kerb Weight Inc Driver (kg): 1963
Kerb Weight Inc Driver (lb): 4328
Kerb Weight Includes Driver: yes
Payload Allowance (kg): 947
Payload Allowance (lb): 2088
Published Kerb Weight (kg): 1963
Published Kerb Weight (lb): 4328
Rear Axle Weight (kg): 1700
Rear Axle Weight (lb): 3748
Tare Weight (kg): 1904
Audio System
Colour Screen: yes
In-Dash CD: yes
Radio Type: Am/Fm
Touch Screen: yes
External Connections
Aux Jack (Front): yes
iPod Connection (Front): yes
USB (Front): yes
Remote Audio Controls
Type: Steering Wheel Mounted
Speakers
Number of Speakers: 6
Bluetooth
Includes Music Streaming: yes
Includes Phone Connection: yes
Entertainment Display Screen
Location: Front
Parking Distance System
Location: Rear
Rear Type: Sensor & Camera
Power Outlet 12V
Location (12V): Boot/Cargo
Location (12V): Front
Smart Card/Smart Key
Includes Keyless Entry: yes
Includes Keyless Start: yes
Type: Automatic
Display Screen
Location: Dashboard Centre 1
Dashboard Centre 1 Screen Size (in): 7.0
Dashboard Centre 1 Touch Screen: yes
Floor Covering
Vehicle Cab Compartment: Textile
Luxury Trim
Centre Floor Console: Alloy Look
Doors: Alloy Look
Gear Selector: Leather
Handbrake Grip: Leather
Instrument Panel: Piano Black
Airbags
Number of Airbags: 7
Crash Test Results
ANCAP Date Tested: 20150721
ANCAP Overall: 5.00
ANCAP Pedestrian: Marginal
ANCAP Rear Crash Protect Head Restraint Rating: Good
ANCAP Standard: Ancap
ANCAP Version Tested: Dual Cab Version
Front Airbag
Location: Driver
Location: Passenger
Front Seat Belts
Driver Height Adjustable: yes
Driver Pre Tensioners: yes
Driver Seat Position: Driver
Passenger Height Adjustable: yes
Passenger Pre Tensioners: yes
Passenger Seat Position: Passenger
Head Restraints
Front Seats Location: Front Seats
Rear Seats Location: Rear Seats
Rear Seats Number: 2
Knee Airbags
Location: Driver
Rear Seat Belts
Center Seat Position: Centre
Center Type: 3-Point
Driver Seat Position: Driver
Passenger Seat Position: Passenger
Side Airbag
Location: Front
Side Curtain Airbag
Location: Front And Rear
Front Seat
Driver Front Seat Power Adjustable: yes
Driver Front Seat Heated: yes
Driver Front Seat Height Type: Electric
Location: Driver
Driver Front Seat Lumbar Type: Electric
Driver Front Seat Reach Type: Electric
Driver Front Seat Type: Bucket
Passenger Front Seat Heated: yes
Location: Passenger
Passenger Front Seat Reach Type: Manual
Passenger Front Seat Type: Bucket
Seat Upholstery
Additional Seat Material: Synthetic Leather
Main Seat Material: Leather
Seating
Capacity: 5
Configuration: 2+3
Cup Holders
Location: Front Seats
Air Conditioning
Type: Fully-Auto
Ventilation System
Digital Display: yes
Power Locks
Operation: Card Key
Intermediate Service
Distance (km): 20000
Distance (miles): 12427
Period (Months): 12
* Average savings based on recent CarExpert customer transactions. Actual savings will vary depending on vehicle make and model, location, stock availability, and other factors.
† Displayed prices exclude on-road costs such as delivery charges, registration fees, number plates, insurance and applicable road taxes. These prices are subject to change without notice and may not reflect current market pricing or dealer offers.
Automotive Vehicle Spec Data & 4K images Powered by JATO Dynamics Ltd
