Nissan Navara RX (2017) price & specs
Save $$$ with CarExpert*
From
$25,990â€
Overview
The 2017 Nissan Navara RX is a rear-wheel drive, 2-door Cab Chassis that was released to the Australian market on 4th October 2016 classified as a D23 Series 2. The Nissan Navara is regarded as a Pickup built in Spain with prices starting at $25,990 before on-road costs.
This Nissan Navara is powered by a 2.3L 4-cylinder engine that has 120 kW of power (at 3750 rpm) and 403 Nm of torque (at 1500 rpm) via a Six-speed Manual transmission. Nissan claims the Navara RX uses 6.4L/100km of Diesel in the combined city and highway cycle while putting out 169g of CO2. It has a 80L fuel tank, meaning it should be able to travel 1250km per full tank
The Nissan Navara measures 1745mm (68.7 inches) in height, 5120mm (201.6 inches) in length, 1790mm (70.5 inches) in width with a 3150mm (124.0 inches) wheelbase that brings about a total of 1551kg (3419.4 lbs) of unladen weight. The Navara RX comes standard with 205/80 R16 front tyres and 205/80 R16 rear tyres. It requires a service every 12 months or 20,000 km, whichever comes first. It has a 36 month, 100,000 km warranty.
The 2017 Nissan Navara RX has a 215mm ground clearance with a 3500kg braked and 750kg unbraked towing capacity.
Trusted Reviews, Smarter Choices, Better Prices
Where expert car reviews meet expert car buying – CarExpert gives you trusted advice, personalised service and real savings on your next new car.
How does the Navara compare?
Quickly see how the 2017 Nissan Navara RX stacks up against its competition.
 Select any benchmark to see more details.
Power to Weight
63.63 - 92.28 kW/t
53.42 kW/t
92.28 kW/t
Fuel Efficiency
6.3 - 9.9 L/100km
6.3 L/100km
10.9 L/100km
Vehicle Range
808 - 1,270 km
688 km
1,270 km
Price
$19,490 - $56,990
$19,490
$149,500
Warranty (Years)
3 years
2 years
5 years
Warranty (Distance)
100,000 km
100,000 km
Unlimited
Years on Sale
2 - 6 years
1 year
4 years
Service Interval
12 months
6 months
12 months
Towing & Off-Road Capability
Gross Vehicle Weight
2,550 - 2,910 kg
2,550 kg
4,490 kg
Gross Comb. Mass
4,138 - 5,910 kg
4,138 kg
11,479 kg
Braked Towing Capacity
1,588 - 3,500 kg
1,588 kg
6,942 kg
Approach Angle
29.5 - 32.5°
20.7°
35°
Departure Angle
23 - 26.7°
20.3°
29°
Ground Clearance Unladen
191 - 230 mm
188 mm
279 mm
Payload Capacity
880 - 1,359 kg
864 kg
1,533 kg
Trusted Reviews, Smarter Choices, Better Prices
Where expert car reviews meet expert car buying – CarExpert gives you trusted advice, personalised service and real savings on your next new car.
Dimensions
5,120 mm
1,790 mm
1,745 mm
| Specification | Measurement |
|---|---|
| Overall Length | 5,120 mm |
| Overall Width | 1,790 mm |
| Overall Height | 1,745 mm |
| Wheelbase | 3,150 mm |
| Turning Circle | 11,800 mm |
| Load Capacity | 1,359 mm |
Looking for complete Nissan Navara size & space specs?
Our Nissan Navara Exterior and Dimensions Page has every measurement you need to know exactly how this vehicle will fit your driving, garage, or work needs.
Sales Data
Nissan Navara Sales rolling 12-months#
Explore Nissan Navara Features & Specs
Compressor
Compressor: Turbo
Emission Control Level
Australia Air Pollution Rating: 5.0
Australia Greenhouse Rating: 6.5
Australia Overall Emission Control Level Rating: 3.5
CO2 Level (Combined): 169
Standard Met: EU5
Engine
Bore Engine: 85.0
Engine (cc): 2298
Engine Configuration: In-Line
Engine Code: Ys23ddt
Engine (L): 2.3
Number of Cylinders: 4
Number of Valves per Cylinder: 4
Stroke Engine: 101.3
Fuel
Generic Primary Fuel Type: Diesel
Minimum Fuel Type: Diesel
Fuel Type: Diesel
Fuel System
Injection Carburetion: Diesel Common Rail
Fuel Tanks
Main Capacity Gal: 21.1
Main Capacity (L): 80
Main Capacity Uk Gallons: 17.6
Main Type: Total
Fuel Consumption
ADR 81/02 Calculated Vehicle Range (km): 1250
ADR 81/02 Calculated Vehicle Range (miles): 777
ADR 81/02 Combined (km/L): 15.6
ADR 81/02 Combined (L/100km): 6.4
ADR 81/02 Combined (miles per UK gallon): 44
ADR 81/02 Combined (mpg): 37
ADR 81/02 Country Highway (km/L): 16.9
ADR 81/02 Country Highway (L/100km): 5.9
ADR 81/02 Country Highway (miles per UK gallon): 48
ADR 81/02 Country Highway (mpg): 40
ADR 81/02 Standard: Adr 81/02
ADR 81/02 Urban (km/L): 13.7
ADR 81/02 Urban (L/100km): 7.3
ADR 81/02 Urban (miles per UK gallon): 39
ADR 81/02 Urban (mpg): 32
Fuel Economy
ADR 81/02 (L/100km): 6.4
Power
Maximum Power (hp/PS): 163
Maximum Power (kW): 120
Maximum Torque (Nm): 403
Measurement Standard: EEC
Primary or Secondary Fuel Power Figure: Primary
Rpm For Maximum Power Low: 3750
Rpm For Maximum Torque Low: 1500
Drive
Driven Wheels: Rear
Transmission
Code: Fs6r31a
Description: Manual
Number of Speeds: 6
Type: Manual
Disc Brakes
Number of Disc Brakes: 2
Number of Ventilated Disc Brakes: 2
Steering Wheel
Height Adjustment: yes
Type: Plastic
Suspension
Location: Front
Front Spring Type: Coil
Front Stabilizer Bar: yes
Front Type: Wishbone
Front Wheel Dependence: Independent
Location: Rear
Rear Spring Type: Leaf
Rear Type: Beam
Rear Wheel Dependence: Rigid
Tires
Front Wheels Tire Load Index: 112
Location: Front
Front Wheels Tire Profile: 80
Front Wheels Tire Type: Conventional/Summer
Front Wheels Tire Width: 205
Rear Wheels Tire Load Index: 112
Rear Wheels Tire Location: Rear
Rear Wheels Tire Profile: 80
Rear Wheels Tire Type: Conventional/Summer
Rear Wheels Tire Width: 205
Wheels
Location: Front
Front Wheels Rim Diameter (In): 16
Front Wheels Rim Type: Steel
Front Wheels Rim Width (In): 7.0
Location: 1
Location: Rear
Rear Rim Diameter (In): 16
Rear Rim Type: Steel
Rear Wheels Rim Width (In): 7.0
Body Style
Body Type: Cab Chassis
Cab Type: Single Cab
Local Body Type: Cab Chassis
Platform Code: F Alpha
Roof Type: Standard
Wheelbase Type: Short
Mud Flaps
Front Mud Flaps Location: Front
External Dimensions
Kerb to Kerb Turning Circle (mm): 11800
Front Overhang (in): 34.3
Front Overhang (mm): 870
Front Track (in): 61.0
Front Track (mm): 1550
Ground Clearance Unladen (in): 8.5
Ground Clearance Unladen (mm): 215
Kerb To Kerb Turning Circle (ft): 38.7
Overall Height (in): 68.7
Overall Height (mm): 1745
Overall Length (in): 201.6
Overall Length (mm): 5120
Overall Width (in): 70.5
Overall Width (mm): 1790
Rear Overhang (in): 43.3
Rear Overhang (mm): 1100
Rear Track (in): 61.0
Rear Track (mm): 1550
Wheelbase (in): 124.0
Wheelbase (mm): 3150
Ramp Angles
Approach Angle: 31.6
Departure Angle: 23.3
Bumpers
Front Bumper Colour: Painted
Location: Front
Doors
Location: Driver
Driver Door Type: Front Hinged
Location: Passenger
Passenger Door Type: Front Hinged
Headlight Control
Dusk Sensor: yes
Headlights
High Beam Bulb Type: Halogen
Low Beam Bulb Type: Halogen
Lens Type: Complex Surface
Paint
External Colour: White
Type: Gloss
Door Mirrors/Cameras
Driver Door Mirrors/Cameras Colour: Chrome
Mirrors/Cameras Location: Driver
Driver Door Mirrors/Cameras Type: Electrically Adjustable
Passenger Door Mirrors/Cameras Colour: Chrome
Mirrors/Cameras Location: Passenger
Passenger Door Mirrors/Cameras Type: Electrically Adjustable
Power Windows
Front Electric Windows: Front
Windshield Wipers
Intermittent Wipe Windshield Wipers: Variable
Weights
Front Axle Weight (kg): 1320
Front Axle Weight (lb): 2910
Gross Trailer Weight Braked (kg): 3500
Gross Trailer Weight Braked (lb): 7716
Gross Trailer Weight Unbraked (kg): 750
Gross Trailer Weight Unbraked (lb): 1653
Gross Train Weight (kg): 5910
Gross Train Weight (lb): 13029
Gross Vehicle Weight (kg): 2910
Gross Vehicle Weight (lb): 6415
Kerb Weight Inc Driver (kg): 1551
Kerb Weight Inc Driver (lb): 3419
Kerb Weight Includes Driver: yes
Payload Allowance (kg): 1359
Payload Allowance (lb): 2996
Published Kerb Weight (kg): 1551
Published Kerb Weight (lb): 3419
Rear Axle Weight (kg): 1750
Rear Axle Weight (lb): 3858
Audio System
In-Dash CD: yes
Radio Type: Am/Fm
External Connections
Aux Jack (Front): yes
iPod Connection (Front): yes
USB (Front): yes
Remote Audio Controls
Type: Steering Wheel Mounted
Speakers
Number of Speakers: 4
Bluetooth
Includes Music Streaming: yes
Includes Phone Connection: yes
Power Outlet 12V
Location (12V): Front
Floor Covering
Vehicle Cab Compartment: Plastic/Rubber
Airbags
Number of Airbags: 7
Crash Test Results
ANCAP Date Tested: 20150721
ANCAP Overall: 5.00
ANCAP Pedestrian: Marginal
ANCAP Rear Crash Protect Head Restraint Rating: Good
ANCAP Standard: Ancap
ANCAP Version Tested: Dual Cab Version
Front Airbag
Location: Driver
Location: Passenger
Front Seat Belts
Driver Height Adjustable: yes
Driver Pre Tensioners: yes
Driver Seat Position: Driver
Passenger Height Adjustable: yes
Passenger Pre Tensioners: yes
Passenger Seat Position: Passenger
Head Restraints
Front Seats Location: Front Seats
Knee Airbags
Location: Driver
Side Airbag
Location: Front
Side Curtain Airbag
Location: Front
Front Seat
Driver Front Seat Height Type: Manual
Location: Driver
Driver Front Seat Reach Type: Manual
Driver Front Seat Type: Bucket
Location: Passenger
Passenger Front Seat Reach Type: Manual
Passenger Front Seat Type: Bucket
Seat Upholstery
Additional Seat Material: Cloth
Main Seat Material: Cloth
Seating
Capacity: 2
Configuration: 2+0
Cup Holders
Location: Front Seats
Air Conditioning
Type: Manual
Power Locks
Operation: Remote
Intermediate Service
Distance (km): 20000
Distance (miles): 12427
Period (Months): 12
