Ram 1500 Limited (2022) price & specs
Save $$$ with CarExpert*
From
$153,950â€
Limited
Overview
The 2022 Ram 1500 Limited is a four-wheel drive, 4-door Utility that was released to the Australian market on 4th September 2022 classified as a DT. The Ram 1500 is regarded as a Pickup built in USA with prices starting at $153,950 before on-road costs.
This Ram 1500 is powered by a 5.7L 8-cylinder engine that has 291 kW of power (at 5600 rpm) and 556 Nm of torque (at 3950 rpm) via an Eight-speed Automatic transmission. RAM claims the 1500 Limited uses 12.2L/100km of Unleaded in the combined city and highway cycle while putting out 283g of CO2. It has a 98L fuel tank, meaning it should be able to travel 803km per full tank
The Ram 1500 measures 1972mm (77.6 inches) in height, 5916mm (232.9 inches) in length, 2017mm (79.4 inches) in width with a 3672mm (144.6 inches) wheelbase that brings about a total of 2749kg (6060.5 lbs) of unladen weight. The 1500 Limited comes standard with 285/45 R22 front tyres and 285/45 R22 rear tyres. It requires a service every 12 months or 12,000 km, whichever comes first. It has a 36 month, 100,000 km warranty.
Trusted Reviews, Smarter Choices, Better Prices
Where expert car reviews meet expert car buying – CarExpert gives you trusted advice, personalised service and real savings on your next new car.
How does the 1500 compare?
Quickly see how the 2022 Ram 1500 Limited stacks up against its competition.
 Select any benchmark to see more details.
Power to Weight
105.86 - 172.44 kW/t
47.8 kW/t
172.44 kW/t
Fuel Efficiency
12.2 L/100km
6.7 L/100km
12.4 L/100km
Vehicle Range
807 - 1,024 km
658 km
1,159 km
Price
$79,950 - $219,950
$23,740
$219,950
Warranty (Years)
3 years
3 years
10 years
Warranty (Distance)
100,000 km
100,000 km
Unlimited
Years on Sale
1 - 5 years
1 year
4 years
Service Interval
6 - 12 months
6 months
12 months
Towing & Off-Road Capability
Gross Vehicle Weight
3,450 - 3,538 kg
2,700 kg
5,352 kg
Gross Comb. Mass
6,878 - 7,713 kg
4,435 kg
12,837 kg
Braked Towing Capacity
3,500 - 4,500 kg
1,800 kg
6,171 kg
Approach Angle
15.2 - 30.2°
15.2°
40.7°
Departure Angle
18.6 - 23.7°
15°
29.2°
Breakover Angle
18.6 - 22°
18°
27°
Ground Clearance Unladen
300 mm
174 mm
300 mm
Payload Capacity
701 - 845 kg
693 kg
1,759 kg
Trusted Reviews, Smarter Choices, Better Prices
Where expert car reviews meet expert car buying – CarExpert gives you trusted advice, personalised service and real savings on your next new car.
Dimensions
5,916 mm
2,017 mm
inc mirror: 2,474 mm
inc mirror: 2,474 mm
1,972 mm
| Specification | Measurement |
|---|---|
| Overall Length | 5,916 mm |
| Overall Width | 2,017 mm |
| Overall Width (Inc Mirror) | 2,474 mm |
| Overall Height | 1,972 mm |
| Wheelbase | 3,672 mm |
| Turning Circle | 14,080 mm |
| Load Capacity | 701 mm |
Looking for complete Ram 1500 size & space specs?
Our Ram 1500 Exterior and Dimensions Page has every measurement you need to know exactly how this vehicle will fit your driving, garage, or work needs.
Sales Data
Ram 1500 Sales rolling 12-months#
Explore Ram 1500 Features & Specs
Bluetooth
Includes Music Streaming: yes
Includes Phone Connection: yes
Cruise Control
Adaptive Cruise Control: yes
Stop Go Function: Stop & Go
Memorised Adjustment
Door Mirror Position: yes
Wheel Position: yes
Mobile Integration
Android Auto: yes
Apple Carplay: yes
Mirrorlink Months Subscription Included: 0
Other Months Subscription Included: 0
Parking Assistance
Location: Front
Location: Rear
Rear Type: Full Auto Park & Perpendicular
Parking Distance System
Location: Front
Front Type: Sensor & Camera
Location: Rear
Rear Type: Sensor & Camera
Location: Side
Side Type: Camera
Power Outlet 12V
Location (12V): Front
Location (12V): Rear
Smart Card/Smart Key
Includes Keyless Entry: yes
Includes Keyless Start: yes
Includes Memory Seat Adjustments: yes
Type: Automatic
Telematics
Breakdown Assistance: yes
Concierge Months Included: Unlimited
Connection Type: Via Sim In Vehicle
USB Charging Port
Location: Front
Voice Activating System
Virtual Assistant: Other
Cylinder Shutdown
Number of Cylinders: 4
Electrical System
Voltage: 12
Emission Control Level
CO2 Level (Combined): 283
Standard Met: EU5
Engine
Bore Engine: 99.5
Engine (cc): 5654
Engine Configuration: V
Engine Code: EZL
Engine (L): 5.7
Number of Cylinders: 8
Number of Valves per Cylinder: 2
Stroke Engine: 90.9
Variable Valve Timing Camshaft: yes
Fuel
Generic Primary Fuel Type: Petrol
Minimum Fuel Octane Number: 91
Minimum Fuel Type: Unleaded
Fuel Type: Unleaded
Octane Number: 91
Fuel System
Injection Carburetion: Multi-Point Injection
Fuel Tanks
Main Capacity Gal: 26.0
Main Capacity (L): 98
Main Capacity Uk Gallons: 21.6
Main Type: Total
Electric Motor
Motor 1 Type: Bisg Belt Integrated Starter Gen
Motor 1 Max Torque Motor (Nm): 176
Motor 1 Number: 1
Electric Power Source
Battery (Ah): 9.0
Battery Cell Count: 12
Battery Cell Type: Pouch
Battery Supplier: Lg Energy Solution
Battery Type: Lithium Ion
Battery Voltage: 48
Maximum Battery (kWh): 0.40
Number of kWh Included: 0
Number of Months Subscription Included: 0
Hybrid Type
Hybrid Type: Mild Hybrid
Computer
Average Fuel Consumption: yes
Average Speed: yes
Instantaneous Fuel Consumption: yes
Range for Remaining Fuel: yes
Display Screen
Location: Dashboard Centre 1
Dashboard Centre 1 Screen Orientation: Fixed
Dashboard Centre 1 Screen Size (in): 12.00
Dashboard Centre 1 Touch Screen: yes
Location: Instrument Cluster 1
Instrument Cluster 1 Screen Size (in): 7.00
Instrument Cluster 1 Touch Screen: yes
Low Tire Pressure Indicator
Displays Pressure Reading: yes
Fuel Consumption
ADR 81/02 Calculated Vehicle Range (km): 807
ADR 81/02 Calculated Vehicle Range (miles): 501
ADR 81/02 Combined (km/L): 8.2
ADR 81/02 Combined (L/100km): 12.2
ADR 81/02 Combined (miles per UK gallon): 23
ADR 81/02 Combined (mpg): 19
ADR 81/02 Standard: Adr 81/02
Fuel Economy
ADR 81/02 (L/100km): 12.2
Power
Maximum Power (hp/PS): 396
Maximum Power (kW): 291
Maximum Torque (Nm): 556
Measurement Standard: SAE
Primary or Secondary Fuel Power Figure: Primary
Rpm For Maximum Power Low: 5600
Rpm For Maximum Torque Low: 3950
Differential Lock
Location: Rear
Drive
Driven Wheels: 4x4
Four-Wheel Drive Type: Part-Time
Selection: Manual
Dual Range Transmission
4wd High High Low Transfer Selection: 4wd High
4wd Low High Low Transfer Selection: 4wd Low
Limited Slip Differential
Location: Rear
Rear Type: Mechanical
Transmission
Code: 8hp70
Description: Automatic With Manual Mode
Low High Gear Ranges: yes
Manual Mode: yes
Number of Speeds: 8
Shift Lever Location: Dash
Type: Automatic
Disc Brakes
Number of Disc Brakes: 4
Number of Ventilated Disc Brakes: 2
Steering Wheel
Height Adjustment: yes
Telescopic Adjustment: yes
Type: Leather Covered
Suspension
Location: Front
Front Spring Type: air
Front Stabilizer Bar: yes
Front Type: Wishbone
Front Wheel Dependence: Independent
Location: Rear
Rear Spring Type: air
Rear Stabilizer Bar: yes
Rear Type: Beam
Rear Wheel Dependence: Rigid
Tires
Location: Front
Front Wheels Tire Profile: 45
Front Wheels Tire Type: All Seasons
Front Wheels Tire Width: 285
Rear Wheels Tire Location: Rear
Rear Wheels Tire Profile: 45
Rear Wheels Tire Type: All Seasons
Rear Wheels Tire Width: 285
Wheels
Location: Front
Front Wheels Rim Diameter (In): 22
Front Wheels Rim Type: Alloy
Location: 1
Location: Rear
Rear Rim Diameter (In): 22
Rear Rim Type: Alloy
Body Style
Body Type: Utility
Cab Type: Double Cab
Local Body Type: Utility
Platform Code: DT
Roof Type: Standard
Wheelbase Type: Long
Mud Flaps
Rear Mud Flaps Location: Rear
Step
Step Location: Rear
Rear Step Type: Platform
Step Location: Side
Tray/Tub
Liner: Spray-In
Type: Straight Side
Cargo Area Dimensions
Cargo Volume (cu ft): 53.0
Cargo Volume (L): 1500
Height (in): 21.4
Height (mm): 1270
Length (in): 67.4
Length (mm): 1712
Loading Floor Height (in): 33.3
Loading Floor Height (mm): 847
Standard Measurement: Manufacturer'S Own
Width (in): 50.0
Width (mm): 1270
External Dimensions
Kerb to Kerb Turning Circle (mm): 14080
Front Track (in): 68.6
Front Track (mm): 1742
Kerb To Kerb Turning Circle (ft): 46.2
Overall Height (in): 77.6
Overall Height (mm): 1972
Overall Length (in): 232.9
Overall Length (mm): 5916
Overall Width Folded Mirror (in): 82.6
Overall Width Folded Mirror (mm): 2097
Overall Width (in): 79.4
Overall Width Inc Mirror (in): 97.4
Overall Width Inc Mirror (mm): 2474
Overall Width (mm): 2017
Rear Track (in): 68.0
Rear Track (mm): 1727
Wheelbase (in): 144.6
Wheelbase (mm): 3672
Ramp Angles
Approach Angle: 24.5
Break Over Angle: 22.0
Departure Angle: 23.2
Bumpers
Front Bumper Colour: Painted
Location: Front
Rear Bumper Colour: Painted
Location: Rear
Cargo Doors
Location: Rear
Rear Opening Angle: 180
Rear Operation: Dropping Gate
Doors
Location: Driver
Driver Door Type: Front Hinged
Location: Passenger
Passenger Door Type: Front Hinged
Location: Rear Driver
Rear Driver Door Type: Front Hinged
Location: Rear Passenger
Rear Passenger Door Type: Front Hinged
Headlight Control
Auto Highbeam: yes
Dusk Sensor: yes
Height Adjustment: Automatic
Headlights
High Beam Bulb Type: LED
Low Beam Bulb Type: LED
Lens Type: Ellipsoidal
LED Lights
Location: Brake Lights
Location: High Beam
Location: Low Beam
Paint
External Colour: Gray
Type: Gloss
Sunroof
Front Sunroof Location: Front
Front Sunroof Operation: Electric
Front Sunroof Type: Glass
Door Mirrors/Cameras
Driver Door Mirrors/Cameras Colour: Painted
Mirrors/Cameras Location: Driver
Driver Door Mirrors/Cameras Type: Electrically Adjustable
Passenger Door Mirrors/Cameras Colour: Painted
Mirrors/Cameras Location: Passenger
Passenger Door Mirrors/Cameras Type: Electrically Adjustable
Power Windows
Front Electric Windows: Front
Rear Electric Windows: Rear
Rear Side Windows
Location: Driver
Driver Type: Wind-Up
Location: Passenger
Passenger Type: Wind-Up
Rear View Mirror Camera
Auto Dimming: yes
Windshield Wipers
Intermittent Wipe Windshield Wipers: Automatic
Rain Sensor Windshield Wipers: yes
Weights
Front Axle Weight (kg): 1860
Front Axle Weight (lb): 4101
Gross Trailer Weight Braked (kg): 4500
Gross Trailer Weight Braked (lb): 9921
Gross Trailer Weight Unbraked (kg): 750
Gross Trailer Weight Unbraked (lb): 1653
Gross Train Weight (kg): 7713
Gross Train Weight (lb): 17004
Gross Vehicle Weight (kg): 3450
Gross Vehicle Weight (lb): 7606
Payload Allowance (kg): 701
Payload Allowance (lb): 1545
Published Kerb Weight (kg): 2749
Published Kerb Weight (lb): 6061
Rear Axle Weight (kg): 1860
Rear Axle Weight (lb): 4101
Tare Weight (kg): 2683
Audio System
Audio Player Reads MP3: yes
Colour Screen: yes
Digital Media Card: yes
Digital Radio: yes
Radio Type: Am/Fm
Touch Screen: yes
External Connections
USB (Front): yes
Remote Audio Controls
Type: Steering Wheel Mounted
Speakers
Number of Speakers: 19
Floor Covering
Vehicle Cab Compartment: Textile
Load Area Side Covering
Type: Plastic/Rubber
Luxury Trim
Doors: Wood Or Woodlook
Gear Selector: Chrome
Instrument Panel: Wood Or Woodlook
Airbags
Number of Airbags: 6
Autonomous Drive
Active Lane Control: yes
Level: 2 - Partial Automation
Front Airbag
Location: Driver
Location: Passenger
Front Seat Belts
Driver Height Adjustable: yes
Driver Pre Tensioners: yes
Driver Seat Position: Driver
Passenger Height Adjustable: yes
Passenger Pre Tensioners: yes
Passenger Seat Position: Passenger
Head Restraints
Front Seats Location: Front Seats
Rear Seats Location: Rear Seats
Rear Seats Number: 3
Lane Departure Warning
Activates Steering: yes
Maximum Speed For Operation (km/h): 180
Maximum Speed For Operation (mph): 112
Overtaking Sensor
Active Without Turn Signal: yes
Buzzer: yes
Includes Display: yes
Includes Trailer Coverage: yes
Rear Cross Traffic Collision Avoidance
Type: Sensor
Rear Seat Belts
Center Seat Position: Centre
Center Type: 3-Point
Driver Seat Position: Driver
Passenger Seat Position: Passenger
Side Airbag
Location: Front
Side Curtain Airbag
Location: Front And Rear
Front Seat
Driver Front Seat Power Adjustable: yes
Driver Front Seat Heated: yes
Driver Front Seat Height Type: Memory
Location: Driver
Driver Front Seat Lumbar Type: 2-Way Electric
Driver Front Seat Reach Type: Memory
Driver Front Seat Reclining Type: Memory
Driver Front Seat Type: Bucket
Passenger Front Seat Power Adjustable: yes
Passenger Front Seat Heated: yes
Passenger Front Seat Height Type: Electric
Location: Passenger
Passenger Front Seat Lumbar Type: 2-Way Electric
Passenger Front Seat Reach Type: Electric
Passenger Front Seat Reclining Type: Electric
Passenger Front Seat Type: Bucket
Seat Upholstery
Additional Seat Material: Synthetic Leather
Main Seat Material: Leather
Seating
Capacity: 5
Configuration: 2+3
Cup Holders
Location: Front Seats
Location: Rear Seats
Air Conditioning
Type: Fully-Auto
Power Locks
Includes Trunk Hatch: yes
Operation: Card Key
Intermediate Service
Distance (km): 12000
Distance (miles): 7456
Period (Months): 12
* Average savings based on recent CarExpert customer transactions. Actual savings will vary depending on vehicle make and model, location, stock availability, and other factors.
†Displayed prices exclude on-road costs such as delivery charges, registration fees, number plates, insurance and applicable road taxes. These prices are subject to change without notice and may not reflect current market pricing or dealer offers.
Automotive Vehicle Spec Data & 4K images Powered by JATO Dynamics Ltd
