Ram 1500 TRX (2022) price & specs
Save $$$ with CarExpert*
From
$199,950†
TRX
Overview
The 2022 Ram 1500 TRX is a four-wheel drive, 4-door Utility that was released to the Australian market on 7th June 2022 classified as a 577. The Ram 1500 is regarded as a Pickup built in USA with prices starting at $199,950 before on-road costs.
This Ram 1500 is powered by a 6.2L 8-cylinder engine that has 523 kW of power (at 6100 rpm) and 882 Nm of torque (at 4800 rpm) via an Eight-speed Automatic transmission. RAM claims the 1500 TRX uses 12.2L/100km of Premium Unleaded in the combined city and highway cycle while putting out nullg of CO2. It has a 125L fuel tank, meaning it should be able to travel 1025km per full tank
The Ram 1500 measures 2055mm (80.9 inches) in height, 5929mm (233.4 inches) in length, 2029mm (79.9 inches) in width with a 3686mm (145.1 inches) wheelbase that brings about a total of 3033kg (6686.6 lbs) of unladen weight. The 1500 TRX comes standard with 325/65 R18 front tyres and 325/65 R18 rear tyres. It requires a service every 6 months or 10,000 km, whichever comes first. It has a 36 month, 100,000 km warranty.
The 2022 Ram 1500 TRX has a 300mm ground clearance with a 3500kg braked and 750kg unbraked towing capacity.
Trusted Reviews, Smarter Choices, Better Prices
Where expert car reviews meet expert car buying – CarExpert gives you trusted advice, personalised service and real savings on your next new car.
How does the 1500 compare?
Quickly see how the 2022 Ram 1500 TRX stacks up against its competition.
Select any benchmark to see more details.
Power to Weight
105.86 - 172.44 kW/t
47.8 kW/t
172.44 kW/t
Fuel Efficiency
12.2 L/100km
6.7 L/100km
12.4 L/100km
Vehicle Range
807 - 1,024 km
658 km
1,159 km
Price
$79,950 - $219,950
$23,740
$219,950
Warranty (Years)
3 years
3 years
10 years
Warranty (Distance)
100,000 km
100,000 km
Unlimited
Years on Sale
1 - 5 years
1 year
4 years
Service Interval
6 - 12 months
6 months
12 months
Towing & Off-Road Capability
Gross Vehicle Weight
3,450 - 3,538 kg
2,700 kg
5,352 kg
Gross Comb. Mass
6,878 - 7,713 kg
4,435 kg
12,837 kg
Braked Towing Capacity
3,500 - 4,500 kg
1,800 kg
6,171 kg
Approach Angle
15.2 - 30.2°
15.2°
40.7°
Departure Angle
18.6 - 23.7°
15°
29.2°
Breakover Angle
18.6 - 22°
18°
27°
Ground Clearance Unladen
300 mm
174 mm
300 mm
Payload Capacity
701 - 845 kg
693 kg
1,759 kg
Trusted Reviews, Smarter Choices, Better Prices
Where expert car reviews meet expert car buying – CarExpert gives you trusted advice, personalised service and real savings on your next new car.
Dimensions
5,929 mm
2,029 mm
inc mirror: 2,480 mm
inc mirror: 2,480 mm
2,055 mm
| Specification | Measurement |
|---|---|
| Overall Length | 5,929 mm |
| Overall Width | 2,029 mm |
| Overall Width (Inc Mirror) | 2,480 mm |
| Overall Height | 2,055 mm |
| Wheelbase | 3,686 mm |
| Turning Circle | 14,700 mm |
| Load Capacity | 505 mm |
Looking for complete Ram 1500 size & space specs?
Our Ram 1500 Exterior and Dimensions Page has every measurement you need to know exactly how this vehicle will fit your driving, garage, or work needs.
Sales Data
Ram 1500 Sales rolling 12-months#
Explore Ram 1500 Features & Specs
Bluetooth
Includes Music Streaming: yes
Includes Phone Connection: yes
Cruise Control
Adaptive Cruise Control: yes
Stop Go Function: Stop & Go
Driver Modes
Engine Mapping: yes
Mobile Integration
Android Auto: yes
Android Number of Months Subscription: Unlimited
Android Wireless Connection: yes
Apple Carplay: yes
Apple Number of Months Subscription: Unlimited
Apple Wireless Connection: yes
Mirrorlink Months Subscription Included: 0
Other Months Subscription Included: 0
Over Air Updates
Type: Ota Updates
Parking Assistance
Location: Front
Location: Rear
Rear Type: Full Auto Park & Perpendicular
Parking Distance System
Location: Front
Front Type: Sensor & Camera
Location: Rear
Rear Type: Sensor & Camera
Location: Side
Side Type: Camera
Power Outlet 12V
Location (12V): Front
Remote Services
Beep Flash: yes
Find My Car: yes
Months Subscription Included: 12
Remote Lock Unlock: yes
Send Destination To Car: yes
Theft Alert: yes
Vehicle Start: yes
Smart Card/Smart Key
Includes Keyless Entry: yes
Includes Keyless Start: yes
Includes Memory Seat Adjustments: yes
Type: Automatic
Telematics
Breakdown Assistance: yes
Connection Type: Via Sim In Vehicle
USB Charging Port
Location: Front
Location: Rear
Voice Activating System
Virtual Assistant: Alexa
Compressor
Compressor: Supercharger
Number of Compressors: 1
Electrical System
Voltage: 12
Emission Control Level
Standard Met: EU5
Engine
Bore Engine: 103.9
Engine (cc): 6166
Engine Configuration: V
Engine Code: ESD
Engine (L): 6.2
Number of Cylinders: 8
Number of Valves per Cylinder: 2
Stroke Engine: 90.9
Variable Valve Timing Camshaft: yes
Additional Fuel Types
Unleaded Fuel: Unleaded
Fuel
Generic Primary Fuel Type: Petrol
Minimum Fuel Octane Number: 95
Minimum Fuel Type: Premium Unleaded
Fuel Type: Premium Unleaded
Octane Number: 95
Fuel System
Injection Carburetion: Multi-Point Injection
Fuel Tanks
Main Capacity Gal: 33.0
Main Capacity (L): 125
Main Capacity Uk Gallons: 27.5
Main Type: Total
Computer
Average Fuel Consumption: yes
Range for Remaining Fuel: yes
Display Screen
Location: Dashboard Centre 1
Dashboard Centre 1 Screen Size (in): 12.0
Dashboard Centre 1 Touch Screen: yes
Location: Instrument Cluster 1
Instrument Cluster 1 Screen Size (in): 7.0
Low Tire Pressure Indicator
Displays Pressure Reading: yes
Fuel Consumption
ADR 81/02 Calculated Vehicle Range (km): 1024
ADR 81/02 Calculated Vehicle Range (miles): 636
ADR 81/02 Combined (km/L): 8.2
ADR 81/02 Combined (L/100km): 12.2
ADR 81/02 Combined (miles per UK gallon): 23
ADR 81/02 Combined (mpg): 19
ADR 81/02 Standard: Adr 81/02
Fuel Economy
ADR 81/02 (L/100km): 12.2
Power
Maximum Power (hp/PS): 702
Maximum Power (kW): 523
Maximum Torque (Nm): 882
Measurement Standard: SAE
Primary or Secondary Fuel Power Figure: Primary
Rpm For Maximum Power Low: 6100
Rpm For Maximum Torque Low: 4800
Differential Lock
Location: Rear
Drive
Driven Wheels: 4x4
Four-Wheel Drive Type: Full And Part-Time
Selection: Manual & Automatic
Dual Range Transmission
4wd High High Low Transfer Selection: 4wd High
4wd Low High Low Transfer Selection: 4wd Low
Transmission
Code: 8hp95
Description: Automatic With Manual Mode
Low High Gear Ranges: yes
Manual Mode: yes
Number of Speeds: 8
Shift Lever Location: Steering Wheel
Type: Automatic
Disc Brakes
Number of Disc Brakes: 4
Number of Ventilated Disc Brakes: 2
Steering Wheel
Height Adjustment: yes
Telescopic Adjustment: yes
Type: Alloy & Leather
Suspension
Location: Front
Front Spring Type: Coil
Front Stabilizer Bar: yes
Front Type: Wishbone
Front Wheel Dependence: Independent
Location: Rear
Rear Spring Type: Coil
Rear Stabilizer Bar: yes
Rear Type: Beam
Rear Wheel Dependence: Rigid
Tires
Location: Front
Front Wheels Tire Profile: 65
Front Wheels Tire Type: All Terrain
Front Wheels Tire Width: 325
Rear Wheels Tire Location: Rear
Rear Wheels Tire Profile: 65
Rear Wheels Tire Type: All Terrain
Rear Wheels Tire Width: 325
Wheels
Location: Front
Front Wheels Rim Diameter (In): 18
Front Wheels Rim Type: Alloy
Front Wheels Rim Width (In): 9.0
Location: 1
Location: Rear
Rear Rim Diameter (In): 18
Rear Rim Type: Alloy
Rear Wheels Rim Width (In): 9.0
Black Trim
Around Side Windows: yes
Exhaust Pipe: yes
Body Style
Body Type: Utility
Cab Type: Double Cab
Local Body Type: Utility
Platform Code: DT
Roof Type: Standard
Wheelbase Type: Short
Mud Flaps
Rear Mud Flaps Location: Rear
Step
Step Location: Rear
Rear Step Type: Platform
Tray/Tub
Lockable Tub Cover: yes
Liner: Composite
Type: Straight Side
Cargo Area Dimensions
Cargo Volume (cu ft): 53.0
Cargo Volume (L): 1500
Height (in): 21.4
Height (mm): 1687
Length (in): 67.4
Length (mm): 1711
Loading Floor Height (in): 38.1
Loading Floor Height (mm): 968
Standard Measurement: Manufacturer'S Own
Width Between Wheelhouses (in): 51.0
Width Between Wheelhouses (mm): 1295
Width (in): 66.4
Width (mm): 1687
External Dimensions
Kerb to Kerb Turning Circle (mm): 14700
Front Track (in): 74.5
Front Track (mm): 1892
Ground Clearance Unladen (in): 11.8
Ground Clearance Unladen (mm): 300
Kerb To Kerb Turning Circle (ft): 48.2
Overall Height (in): 80.9
Overall Height (mm): 2055
Overall Length (in): 233.4
Overall Length (mm): 5929
Overall Width Folded Mirror (in): 88.0
Overall Width Folded Mirror (mm): 2235
Overall Width (in): 79.9
Overall Width Inc Mirror (in): 97.6
Overall Width Inc Mirror (mm): 2480
Overall Width (mm): 2029
Rear Track (in): 74.1
Rear Track (mm): 1882
Wheelbase (in): 145.1
Wheelbase (mm): 3686
Ramp Angles
Approach Angle: 30.2
Departure Angle: 23.5
Bumpers
Front Bumper Colour: Toned
Location: Front
Rear Bumper Colour: Painted
Location: Rear
Cargo Doors
Location: Rear
Rear Opening Angle: 180
Rear Operation: Dropping Gate
Doors
Location: Driver
Driver Door Type: Front Hinged
Location: Passenger
Passenger Door Type: Front Hinged
Location: Rear Driver
Rear Driver Door Type: Front Hinged
Location: Rear Passenger
Rear Passenger Door Type: Front Hinged
Headlight Control
Auto Highbeam: yes
Dusk Sensor: yes
Height Adjustment: Automatic
Headlights
High Beam Bulb Type: LED
Low Beam Bulb Type: LED
Lens Type: Ellipsoidal
LED Lights
Location: Brake Lights
Location: High Beam
Location: Low Beam
Paint
External Colour: Gray
Type: Metallic
Sunroof
Front to Rear Sunroof Location: Front To Rear
Front to Rear Sunroof Operation: Electric
Front to Rear Sunroof Sunshade: yes
Front to Rear Sunroof Type: Glass
Door Mirrors/Cameras
Driver Door Mirrors/Cameras Colour: Black
Mirrors/Cameras Location: Driver
Driver Door Mirrors/Cameras Type: Electrically Adjustable
Passenger Door Mirrors/Cameras Colour: Black
Mirrors/Cameras Location: Passenger
Passenger Door Mirrors/Cameras Type: Electrically Adjustable
Power Windows
Front Electric Windows: Front
Rear Electric Windows: Rear
Rear Side Windows
Location: Driver
Driver Type: Wind-Up
Location: Passenger
Passenger Type: Wind-Up
Rear View Mirror Camera
Auto Dimming: yes
Windshield Wipers
Intermittent Wipe Windshield Wipers: Automatic
Rain Sensor Windshield Wipers: yes
Weights
Front Axle Weight (kg): 1950
Front Axle Weight (lb): 4299
Gross Trailer Weight Braked (kg): 3500
Gross Trailer Weight Braked (lb): 7716
Gross Trailer Weight Unbraked (kg): 750
Gross Trailer Weight Unbraked (lb): 1653
Gross Train Weight (kg): 6878
Gross Train Weight (lb): 15163
Gross Vehicle Weight (kg): 3538
Gross Vehicle Weight (lb): 7800
Payload Allowance (kg): 767
Payload Allowance (lb): 1691
Published Kerb Weight (kg): 3033
Published Kerb Weight (lb): 6687
Rear Axle Weight (kg): 1905
Rear Axle Weight (lb): 4200
Tare Weight (kg): 2947
Audio System
Audio Player Reads MP3: yes
Brand Name: Harman/Kardon
Colour Screen: yes
Digital Radio: yes
Radio Type: Am/Fm
Touch Screen: yes
External Connections
USB (Front): yes
USB (Rear): yes
Remote Audio Controls
Type: Steering Wheel Mounted
Speakers
Number of Speakers: 19
Floor Covering
Vehicle Cab Compartment: Textile
Luxury Trim
Centre Floor Console: Alloy Look
Doors: Alloy Look
Gear Selector: Leather
Instrument Panel: Alloy Look
Airbags
Number of Airbags: 6
Autonomous Drive
Active Lane Control: yes
Level: 2 - Partial Automation
Front Airbag
Location: Driver
Location: Passenger
Front Seat Belts
Driver Height Adjustable: yes
Driver Pre Tensioners: yes
Driver Seat Position: Driver
Passenger Height Adjustable: yes
Passenger Pre Tensioners: yes
Passenger Seat Position: Passenger
Head Restraints
Front Seats Location: Front Seats
Rear Seats Location: Rear Seats
Rear Seats Number: 3
Lane Departure Warning
Activates Steering: yes
Maximum Speed For Operation (km/h): 180
Maximum Speed For Operation (mph): 112
Overtaking Sensor
Active Without Turn Signal: yes
Buzzer: yes
Includes Display: yes
Includes Trailer Coverage: yes
Rear Cross Traffic Collision Avoidance
Type: Sensor
Rear Seat Belts
Center Seat Position: Centre
Center Type: 3-Point
Driver Seat Position: Driver
Passenger Seat Position: Passenger
Side Airbag
Location: Front
Side Curtain Airbag
Location: Front And Rear
Front Seat
Driver Front Seat Power Adjustable: yes
Driver Front Seat Heated: yes
Driver Front Seat Height Type: Memory
Location: Driver
Driver Front Seat Lumbar Type: 2-Way Electric
Driver Front Seat Reach Type: Memory
Driver Front Seat Reclining Type: Memory
Driver Front Seat Type: Bucket
Passenger Front Seat Power Adjustable: yes
Passenger Front Seat Heated: yes
Passenger Front Seat Height Type: Electric
Location: Passenger
Passenger Front Seat Lumbar Type: 2-Way Electric
Passenger Front Seat Reach Type: Electric
Passenger Front Seat Reclining Type: Electric
Passenger Front Seat Type: Bucket
Seat Upholstery
Additional Seat Material: Leather
Main Seat Material: Synthetic Suede
Seating
Capacity: 5
Configuration: 2+3
Cup Holders
Location: Front Seats
Location: Rear Seats
Air Conditioning
Type: Fully-Auto
Ventilation System
Touch Screen Controls: yes
Power Locks
Operation: Card Key
Intermediate Service
Distance (km): 10000
Distance (miles): 6214
Period (Months): 6
* Average savings based on recent CarExpert customer transactions. Actual savings will vary depending on vehicle make and model, location, stock availability, and other factors.
† Displayed prices exclude on-road costs such as delivery charges, registration fees, number plates, insurance and applicable road taxes. These prices are subject to change without notice and may not reflect current market pricing or dealer offers.
Automotive Vehicle Spec Data & 4K images Powered by JATO Dynamics Ltd
