Base
2.5L, 6-speed manual, 5-door Panel Van, Diesel, RWD
Save $$$ with CarExpert*
$36,490â€
Hyundai iLoad Base (2015) price & specs
Save $$$ with CarExpert*
From
$36,490â€
Base
Overview
The 2015 Hyundai iLoad Base is a rear-wheel drive, 5-door Panel Van that was released to the Australian market on 4th January 1970 classified as a TQ2. The Hyundai iLoad is regarded as a Van Under 3.5t built in Turkey with prices starting at $36,490 before on-road costs.
This Hyundai iLoad is powered by a 2.5L 4-cylinder engine that has 100 kW of power (at 3800 rpm) and 343 Nm of torque (at 1500 rpm) via a Six-speed Manual transmission. Hyundai claims the iLoad Base uses 8.0L/100km of Diesel in the combined city and highway cycle while putting out 212g of CO2. It has a 75L fuel tank, meaning it should be able to travel 938km per full tank
The Hyundai iLoad measures 1935mm (76.2 inches) in height, 5125mm (201.8 inches) in length, 1920mm (75.6 inches) in width with a 3200mm (126.0 inches) wheelbase that brings about a total of 2047kg (4512.9 lbs) of unladen weight. The iLoad Base comes standard with 215/70 R16 front tyres and 215/70 R16 rear tyres. It requires a service every 12 months or 15,000 km, whichever comes first. It has a 60 month, 160,000 km warranty.
The 2015 Hyundai iLoad Base has a 190mm ground clearance with a 2000kg braked and 750kg unbraked towing capacity.
Trusted Reviews, Smarter Choices, Better Prices
Where expert car reviews meet expert car buying – CarExpert gives you trusted advice, personalised service and real savings on your next new car.
How does the iLoad compare?
Quickly see how the 2015 Hyundai iLoad Base stacks up against its competition.
 Select any benchmark to see more details.
Power to Weight
47.46 - 66.39 kW/t
39.64 kW/t
75.86 kW/t
Fuel Efficiency
8 - 10.1 L/100km
4.9 L/100km
10.8 L/100km
Vehicle Range
743 - 938 km
648 km
1,290 km
Price
$30,990 - $40,990
$22,000
$57,190
Warranty (Years)
5 years
3 years
5 years
Warranty (Distance)
160,000 km
100,000 km
Unlimited
Service Interval
12 months
6 months
12 months
Towing & Off-Road Capability
Gross Vehicle Weight
2,950 - 3,230 kg
2,030 kg
3,230 kg
Gross Comb. Mass
4,450 - 5,160 kg
3,800 kg
5,200 kg
Braked Towing Capacity
1,500 - 2,000 kg
1,000 kg
2,000 kg
Ground Clearance Unladen
190 mm
152 mm
190 mm
Payload Capacity
1,007 - 1,123 kg
659 kg
1,351 kg
Trusted Reviews, Smarter Choices, Better Prices
Where expert car reviews meet expert car buying – CarExpert gives you trusted advice, personalised service and real savings on your next new car.
Dimensions
5,125 mm
1,920 mm
1,935 mm
| Specification | Measurement |
|---|---|
| Overall Length | 5,125 mm |
| Overall Width | 1,920 mm |
| Overall Height | 1,935 mm |
| Wheelbase | 3,200 mm |
| Turning Circle | 11,220 mm |
| Load Capacity | 1,113 mm |
Looking for complete Hyundai iLoad size & space specs?
Our Hyundai iLoad Exterior and Dimensions Page has every measurement you need to know exactly how this vehicle will fit your driving, garage, or work needs.
Explore Hyundai iLoad Features & Specs
Compressor
Compressor: Turbo
Emission Control Level
Australia Air Pollution Rating: 3.0
Australia Greenhouse Rating: 6.0
Australia Overall Emission Control Level Rating: 2.5
CO2 Level (Combined): 212
Standard Met: EU4
Engine
Bore Engine: 91.0
Engine (cc): 2497
Engine Configuration: In-Line
Engine Code: VGT
Engine (L): 2.5
Number of Cylinders: 4
Number of Valves per Cylinder: 4
Stroke Engine: 96.0
Fuel
Generic Primary Fuel Type: Diesel
Minimum Fuel Type: Diesel
Fuel Type: Diesel
Fuel System
Injection Carburetion: Diesel Common Rail
Fuel Tanks
Main Capacity Gal: 19.8
Main Capacity (L): 75
Main Capacity Uk Gallons: 16.5
Main Type: Total
Fuel Consumption
ADR 81/02 Calculated Vehicle Range (km): 938
ADR 81/02 Calculated Vehicle Range (miles): 583
ADR 81/02 Combined (km/L): 12.5
ADR 81/02 Combined (L/100km): 8.0
ADR 81/02 Combined (miles per UK gallon): 35
ADR 81/02 Combined (mpg): 29
ADR 81/02 Country Highway (km/L): 14.7
ADR 81/02 Country Highway (L/100km): 6.8
ADR 81/02 Country Highway (miles per UK gallon): 42
ADR 81/02 Country Highway (mpg): 35
ADR 81/02 Standard: Adr 81/02
ADR 81/02 Urban (km/L): 9.8
ADR 81/02 Urban (L/100km): 10.2
ADR 81/02 Urban (miles per UK gallon): 28
ADR 81/02 Urban (mpg): 23
Fuel Economy
ADR 81/02 (L/100km): 8.0
Power
Maximum Power (hp/PS): 136
Maximum Power (kW): 100
Maximum Torque (Nm): 343
Measurement Standard: EEC
Primary or Secondary Fuel Power Figure: Primary
Rpm For Maximum Power Low: 3800
Rpm For Maximum Torque Low: 1500
Drive
Driven Wheels: Rear
Transmission
Description: Manual
Number of Speeds: 6
Type: Manual
Disc Brakes
Number of Disc Brakes: 4
Number of Ventilated Disc Brakes: 4
Power Steering
Type: Hydraulic
Steering Wheel
Height Adjustment: yes
Type: Plastic
Suspension
Location: Front
Front Spring Type: Coil
Front Stabilizer Bar: yes
Front Type: Strut
Front Wheel Dependence: Independent
Location: Rear
Rear Spring Type: Leaf
Rear Type: Beam
Rear Wheel Dependence: Rigid
Tires
Front Wheels Tire Load Index: 108
Location: Front
Front Wheels Tire Profile: 70
Front Wheels Tire Type: Extra Load
Front Wheels Tire Width: 215
Rear Wheels Tire Load Index: 108
Rear Wheels Tire Location: Rear
Rear Wheels Tire Profile: 70
Rear Wheels Tire Type: Extra Load
Rear Wheels Tire Width: 215
Wheels
Location: Front
Front Wheels Rim Diameter (In): 16
Front Wheels Rim Type: Steel
Front Wheels Rim Width (In): 6.5
Location: 1
Location: Rear
Rear Rim Diameter (In): 16
Rear Rim Type: Steel
Rear Wheels Rim Width (In): 6.5
Body Style
Body Type: Panel Van
Local Body Type: Panel Van
Platform Code: CK
Roof Type: Standard
Wheelbase Type: Short
Mud Flaps
Front Mud Flaps Location: Front
Rear Mud Flaps Location: Rear
Bumpers
Front Bumper Colour: Painted
Location: Front
Rear Bumper Colour: Black
Location: Rear
Cargo Area Dimensions
Cargo Volume (cu ft): 156.3
Cargo Volume (L): 4426
Height (in): 53.1
Height (mm): 1620
Length (in): 93.5
Length (mm): 2375
Loading Floor Height (in): 23.8
Loading Floor Height (mm): 605
Standard Measurement: Manufacturer'S Own
Width Between Wheelhouses (in): 49.6
Width Between Wheelhouses (mm): 1260
Width (in): 63.8
Width (mm): 1620
External Dimensions
Kerb to Kerb Turning Circle (mm): 11220
Front Track (in): 66.3
Front Track (mm): 1685
Ground Clearance Unladen (in): 7.5
Ground Clearance Unladen (mm): 190
Kerb To Kerb Turning Circle (ft): 36.8
Overall Height (in): 76.2
Overall Height (mm): 1935
Overall Length (in): 201.8
Overall Length (mm): 5125
Overall Width (in): 75.6
Overall Width (mm): 1920
Rear Track (in): 65.4
Rear Track (mm): 1660
Wheelbase (in): 126.0
Wheelbase (mm): 3200
Cargo Doors
Driver Height (in): 62.2
Driver Height (mm): 1580
Driver Location: Driver
Driver Operation: Sliding
Driver Width (in): 48.2
Driver Width (mm): 1225
Passenger Height (in): 62.2
Passenger Height (mm): 1580
Location: Passenger
Passenger Operation: Sliding
Passenger Width (in): 48.2
Passenger Width (mm): 1225
Rear Height (in): 54.7
Rear Height (mm): 1390
Location: Rear
Rear Opening Angle: 90
Rear Operation: Lifting Gate
Rear Width (in): 60.6
Rear Width (mm): 1540
Doors
Location: Driver
Driver Door Type: Front Hinged
Location: Passenger
Passenger Door Type: Front Hinged
Rear Door
Type: Double Hinged
Headlights
High Beam Bulb Type: Halogen
Low Beam Bulb Type: Halogen
Lens Type: Complex Surface
Paint
External Colour: Silver
Type: Gloss
Door Mirrors/Cameras
Driver Door Mirrors/Cameras Colour: Black
Mirrors/Cameras Location: Driver
Driver Door Mirrors/Cameras Type: Electrically Adjustable
Passenger Door Mirrors/Cameras Colour: Black
Mirrors/Cameras Location: Passenger
Passenger Door Mirrors/Cameras Type: Electrically Adjustable
Power Windows
Front Electric Windows: Front
Windshield Wipers
Intermittent Wipe Windshield Wipers: Variable
Weights
Gross Trailer Weight Braked (kg): 2000
Gross Trailer Weight Braked (lb): 4409
Gross Trailer Weight Unbraked (kg): 750
Gross Trailer Weight Unbraked (lb): 1653
Gross Train Weight (kg): 5160
Gross Train Weight (lb): 11376
Gross Vehicle Weight (kg): 3160
Gross Vehicle Weight (lb): 6967
Payload Allowance (kg): 1113
Payload Allowance (lb): 2454
Published Kerb Weight (kg): 2047
Published Kerb Weight (lb): 4513
Tare Weight (kg): 1992
Audio System
CD Player Reads MP3: yes
In-Dash CD: yes
Radio Type: Am/Fm
External Connections
Aux Jack (Front): yes
iPod Connection (Front): yes
USB (Front): yes
Remote Audio Controls
Type: Steering Wheel Mounted
Speakers
Number of Speakers: 2
Bluetooth
Includes Music Streaming: yes
Includes Phone Connection: yes
Power Outlet 12V
Location (12V): Front
Luxury Trim
Gear Selector: Alloy Look
Airbags
Number of Airbags: 2
Crash Test Results
ANCAP Date Tested: 20090721
ANCAP Overall: 4.00
ANCAP Pedestrian: 1
ANCAP Standard: Ancap
ANCAP Version Tested: 2.4 Manual Van
Front Airbag
Location: Driver
Location: Passenger
Front Seat Belts
Center Seat Position: Center
Driver Height Adjustable: yes
Driver Pre Tensioners: yes
Driver Seat Position: Driver
Passenger Height Adjustable: yes
Passenger Pre Tensioners: yes
Passenger Seat Position: Passenger
Head Restraints
Front Seats Location: Front Seats
Front Seat
Location: Centre
Center Front Seat Type: Bench
Driver Front Seat Height Type: Manual
Location: Driver
Driver Front Seat Reach Type: Manual
Driver Front Seat Type: Bucket
Location: Passenger
Passenger Front Seat Reach Type: Manual
Passenger Front Seat Type: Bench
Seat Upholstery
Additional Seat Material: Cloth
Main Seat Material: Cloth
Seating
Capacity: 3
Configuration: 3+0
Cup Holders
Location: Front Seats
Air Conditioning
Type: Manual
Power Locks
Operation: Remote
Intermediate Service
Distance (km): 15000
Distance (miles): 9321
Period (Months): 12
